Quick Details
-
Productivity:
-
180M3/H
-
Place of Origin:
-
China
-
Brand Name:
-
Newindu
-
Weight:
-
16000 kg
-
Dimension(L*W*H):
-
9845*2500*3596mm
-
Concrete hopper capacity:
-
600L
-
Section numbers:
-
6
-
End hose lenght:
-
3m
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
56m
-
Max. horizontal conveying distance:
-
120M
-
Productivity:
-
180M3/H
-
Place of Origin:
-
China
-
Brand Name:
-
Newindu
-
Weight:
-
16000 kg
-
Dimension(L*W*H):
-
9845*2500*3596mm
-
Concrete hopper capacity:
-
600L
-
Section numbers:
-
6
-
End hose lenght:
-
3m
Hot Sale 56X-6RZ Towed Diesel Concrete Pump Portable Concrete Pump Machine
Contact Way
Sales Manager
Camille Su
Newindu Construction Engineering (Shanghai) Co.,Ltd
Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China
Tel: +86-21-62770109 Fax: +86-21-62120109
Mobile / Whatsapp/ Skype/Wechat:
+86-17805097948
Web:
www.newindu.com
Products Description
• Compact in design, 56m pump mounted on 4-axle truck.
• Active boom vibration control technology(ABC):All-position active vibration reduction technology of boom, reducing vibration by 50%. More stable boom, more safety.
• Boom intelligent damping technology:The soft control of booms in starting, slewing and stopping reduces the impacting vibration of booms and therefore makes the vehicle operate more stably, reliably and safely.
• Accurate pumping control technology(APC):Great leap of pumping accuracy and adaptability, improving pump efficiency.
• Adaptive concrete material pumping technology: Improve pumping control system for poor concrete with segregation and big viscosity, and auto-adaptive pumping mode, reducing the block rate by more than 50%.
Product Paramenters
|
Model
|
|
Unit
|
56X-6RZ
|
|
|
Pump Unit
|
Maximum theorical output
|
m3/h
|
180
|
|
|
|
Maximum pressure on concrete
|
bar
|
113
|
|
|
|
Conc. cylinders (diam. x stroke)
|
mm
|
260x2100
|
|
|
|
Concrete hopper capacity
|
L
|
600
|
|
|
|
Hydraulic circuit
|
|
closed
|
|
|
Boom Section
|
Maximum vertical reach
|
m
|
56
|
|
|
|
Maximum horizontal distance
|
m
|
51
|
|
|
|
Minimum unfolding height
|
m
|
15.8
|
|
|
|
Section numbers
|
|
6
|
|
|
|
Rotating angle
|
|
±270°
|
|
|
|
End hose lenght
|
m
|
3
|
|
Product Image
