Quick Details
-
Table Travel (Y) (mm):
-
550
-
Dimension(L*W*H):
-
2850*2390*2600 mm
-
Weight (T):
-
5.5 T
-
Range of Spindle Speed(r.p.m):
-
1 - 8000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Max. Table Load(kg):
-
500 kg
-
Feed Speed(mm/min):
-
1 - 10000 mm/min
-
Rapid Feed Speed(m/min):
-
48/48/48
-
Place of Origin:
-
China
-
Brand Name:
-
HAISEN
-
Voltage:
-
380V
-
Worktable surface:
-
120-670 mm
-
Worktable T slot:
-
5/18*90 mm
-
Spindle center to column:
-
595 mm
-
Spindle Turning speed:
-
8000 rpm
-
Spindle Torque:
-
35 Nm
-
Tool length:
-
300 mm
-
Tool weight:
-
8 KG
-
Air Pressure:
-
6 Kgf/cm²
-
Power supply:
-
20 V(KVA)
-
After Warranty Service:
-
Video technical support
Quick Details
-
Table Size (mm):
-
1000x550
-
Number of Axes:
-
3
-
Table Travel (X) (mm):
-
800
-
Table Travel (Y) (mm):
-
550
-
Dimension(L*W*H):
-
2850*2390*2600 mm
-
Weight (T):
-
5.5 T
-
Range of Spindle Speed(r.p.m):
-
1 - 8000 r.p.m
-
Spindle Motor Power(kW):
-
7.5
-
Max. Table Load(kg):
-
500 kg
-
Feed Speed(mm/min):
-
1 - 10000 mm/min
-
Rapid Feed Speed(m/min):
-
48/48/48
-
Place of Origin:
-
China
-
Brand Name:
-
HAISEN
-
Voltage:
-
380V
-
Worktable surface:
-
120-670 mm
-
Worktable T slot:
-
5/18*90 mm
-
Spindle center to column:
-
595 mm
-
Spindle Turning speed:
-
8000 rpm
-
Spindle Torque:
-
35 Nm
-
Tool length:
-
300 mm
-
Tool weight:
-
8 KG
-
Air Pressure:
-
6 Kgf/cm²
-
Power supply:
-
20 V(KVA)
-
After Warranty Service:
-
Video technical support
|
Main Parameters
|
Unit
|
MLH650
|
MLH850
|
MLH855
|
MLH1055
|
MLH1060
|
|
Worktable size
|
mm
|
410*700
|
500*1000
|
550*1000
|
550*1120
|
620*1300
|
|
X/Y/Z axis travel
|
mm
|
600/500/500
|
800/500/500
|
800/550/550
|
1050/550/550
|
1000/600/600
|
|
X/Y/Z rapid traverse speed
|
m/min
|
48/48/48
|
48/48/48
|
48/48/48
|
48/48/48
|
36/36/36
|
|
Worktable load
|
kg
|
450
|
520
|
550
|
800
|
800
|
|
Spindle taper
|
/
|
BT40
|
BT40
|
BT40
|
BT40
|
BT40
|
|
Spindle speed
|
rpm
|
8000(12000)
|
8000(12000)
|
8000(12000)
|
12000(18000)
|
8000(12000)
|
|
Spindle power
|
Kw
|
5.5
|
7.5
|
7.5
|
11
|
11
|
|
Positioning accuracy
|
mm
|
0.005/300
|
0.005/300
|
0.005/300
|
0.005/300
|
0.005/300
|
|
REpeated positioning accuracy
|
mm
|
0.003/300
|
0.003/300
|
0.003/300
|
0.003/300
|
0.003/300
|
|
Main Parameters
|
Unit
|
MLH1270
|
MLH1380
|
MLH1580
|
MLH1690
|
MLH1890
|
|
Worktable size
|
mm
|
700*1360
|
800*1400
|
800*1600
|
900*1800
|
900*2000
|
|
X/Y/Z axis travel
|
mm
|
1200/700/600
|
1300/800/700
|
1500/800/700
|
1600/900/680
|
1800/900/680
|
|
X/Y/Z rapid traverse speed
|
m/min
|
24/24/15
|
30/30/30
|
30/30/30
|
24/24/15
|
24/24/15
|
|
Worktable load
|
kg
|
1000
|
1000
|
1100
|
1600
|
1600
|
|
Spindle taper
|
/
|
BT50
|
BT50
|
BT50
|
BT50
|
BT50
|
|
Spindle speed
|
rpm
|
8000
|
8000
|
8000
|
8000
|
8000
|
|
Spindle power
|
Kw
|
15(18.5)
|
15(18.5)
|
15(18.5)
|
18.5(22)
|
18.5(22)
|
|
Positioning accuracy
|
mm
|
0.005/300
|
0.005/300
|
0.008/300
|
0.008/300
|
0.008/300
|
|
REpeated positioning accuracy
|
mm
|
0.003/300
|
0.003/300
|
0.005/300
|
0.005/300
|
0.005/300
|
