Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
FANBAO
-
Model Number:
-
ZH650R
-
Warranty:
-
12 Months
-
Color:
-
Customer Request
-
Certification:
-
CE / ISO9001
-
Outside clamping:
-
10"-21"
-
Inside clamping:
-
12"-24"
Quick Details
-
Motor Power:
-
0.75/1.1kw
-
Operating Pressure:
-
8-10bar
-
Power Supply:
-
220V/380V
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
FANBAO
-
Model Number:
-
ZH650R
-
Warranty:
-
12 Months
-
Color:
-
Customer Request
-
Certification:
-
CE / ISO9001
-
Outside clamping:
-
10"-21"
-
Inside clamping:
-
12"-24"
Product Description
| Model: | ZH665R |
| Specification | pneumatically operated tilting column with right help arm,aplly rim max 26" |
| Power: | 1.1kw/0.75kw |
| Power supply: | 220V/380V |
| Max.wheel diameter: | 45″(1140mm) |
| Max.wheel width: | 14″(355mm) |
| Outside clamping: | 12″~23″ |
| Inside clamping: | 14"~26" |
| Air supply: | 8bar-10bar |
| Bead breaker force: | 2500kg |
| Noise level: | <70dB |
| Packing size: | 1130mm*900mm*960mm(main body) |
| 1240mm*380*300mm(right help arm) |
Features:
1.For standard ,low-profile and run-flat wheels of car and light commercial vehicles.
2.Pneumatically operated tilting back post.
3.Double help arm.
4.Locking rim form 12-26".
5.Pedal assembly may draw from front cover.
6.Larger main body and turning table.
7.Bigger bead breaker cylinder Φ200,more powerful.
