Quick Details
-
Model Number:
-
385/65R22.5
-
Tire Size:
-
385/65R22.5
-
Certificate-1:
-
ISO9001
-
Certificate-2:
-
E4/Pah-free/EU Labeling
-
Certificate-3:
-
DOT
-
Certificate-4:
-
M+S
-
Certificate-5:
-
Inmetro
-
Certificate-6:
-
SASO/SN/SNI/SABS
-
Material:
-
Natural Rubber
-
Warranty:
-
1 year
-
MOQ:
-
1*20GP
-
PAYMENT:
-
Accept 30% Deposit 70%balance
Quick Details
-
OE NO.:
-
40112000
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Goodride/Westlake
-
Model Number:
-
385/65R22.5
-
Tire Size:
-
385/65R22.5
-
Certificate-1:
-
ISO9001
-
Certificate-2:
-
E4/Pah-free/EU Labeling
-
Certificate-3:
-
DOT
-
Certificate-4:
-
M+S
-
Certificate-5:
-
Inmetro
-
Certificate-6:
-
SASO/SN/SNI/SABS
-
Material:
-
Natural Rubber
-
Warranty:
-
1 year
-
MOQ:
-
1*20GP
-
PAYMENT:
-
Accept 30% Deposit 70%balance
WESTLAKE / WEST LAKE Truck Tyre
Pattern Description:
1. Aggressive lug design with large blocks at tread center provides excellent traction and braking on rough roads with mud or gravel and is self-cleaning for ease of maintenance.
2. Applicable in mining, logging, construction or rock and quarry operation with some very short on high-way use possible.
3. Special tread compounds resist chipping and chunking off-road conditions.
|
Specification:
|
||||||||||
| Size | LR/PR | Service Inde | Tread Depth | Standard Rim | Overall Diameter | Section Width | Max. Load Capacity at Cold Inflation Pressure | |||
| (mm) | (mm) | (mm) | Single (KG) | Single (KPA) | DUAL (KG) | DUAL (KPA) | ||||
| 9.00R20 | H/16 | 144/142F | 22 | 7 | 1019 | 259 | 2800 | 900 | 2650 | 900 |
| 10.00R20 | J/18 | 149/146F | 24 | 7.5 | 1065 | 278 | 3250 | 930 | 3000 | 930 |
| 11.00R20 | J/18 | 152/149F | 24.5 | 8 | 1096 | 293 | 3550 | 930 | 3250 | 930 |
| 12.00R20 | J/18 | 154/151F | 25.5 | 8.5 | 1136 | 315 | 3750 | 830 | 3450 | 830 |
| 12.00R24 | J/18 | 158/155F | 25 | 8.5 | 1226 | 315 | 4250 | 830 | 3875 | 830 |
| 12.00R24 | J/18 | 158/155F | 32 | 8.5 | 1238 | 315 | 4250 | 830 | 3875 | 830 |
| 11R22.5 | H/16 | 148/145J | 23 | 8.25 | 1065 | 279 | 3150 | 850 | 2900 | 850 |
| 12R22.5 | H/16 | 150/147F | 24.5 | 9 | 1096 | 300 | 3350 | 830 | 3075 | 830 |
| 12R22.5 | J/18 | 152/149F | 24.5 | 9 | 1096 | 300 | 3350 | 930 | 3250 | 930 |
| 12.00R24 | L/20 | 160/157C | 23 | 8.5 | 1238 | 315 | 4250 | 830 | 3875 | 830 |
