Quick Details
-
Interface:
-
RS232 can be customized
-
Color:
-
As shown
-
CPU:
-
Windows
-
Life of automatic cutter:
-
over 1,000,000 cuts
-
Installation:
-
built-in, embedded
-
Warranty:
-
1 Year
-
Working temperature:
-
-40-+70°C
-
Environmental adaptability:
-
Weather-proof (IP54 compliant), dust-proof,
-
Power Supply:
-
DC24V ± 5%
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MT/PT
-
Model Number:
-
PT100
-
Interface:
-
RS232 can be customized
-
Color:
-
As shown
-
CPU:
-
Windows
-
Life of automatic cutter:
-
over 1,000,000 cuts
-
Installation:
-
built-in, embedded
-
Warranty:
-
1 Year
-
Working temperature:
-
-40-+70°C
-
Environmental adaptability:
-
Weather-proof (IP54 compliant), dust-proof,
-
Power Supply:
-
DC24V ± 5%
1: H i g h reliability and durability
2 : Thermal printing
3 : Printing width: 48/54mm (options by commands)
4 : Printing with high graphic quality (speed up to 120mm/sec)
5 : Highly reliable automatic cutter, over 1,000,000 cuts
6 : With self-test and full status monitor function
7 : V arious interface (customized)
8 : Weather-proof (IP54 compliant), dust-proof, environmental adaptability
9 : Specially designed for fuel & gas station environment
|
CATEGORY |
Details |
|
PRINTING METHOD |
Thermal Printing |
|
PRINTING RESOLUTION |
384/432 dpi(8 dots/mm) |
|
PRINTING SPEED |
>120mm/sec |
|
PRINTING WIDTH |
48/54 mm |
|
PRINTING PAPER |
External Diameter: 50mm Internal Diameter: 12.5mm Paper Width: 57.5±0.5mm Paper Thickness: 65±0.5um |
|
CHARACTER SET |
IBM, GB2312 |
|
EMULATION |
ESC/POS |
|
INTERFACE |
RS232 |
|
BAUD RATE |
9600/19200bps |
|
POWER SUPPLY |
DC24V ± 5% |
|
CURRENT |
< 2 A ( +24V ) |
|
DATA BUFFER |
8K |
|
OPERATING SYSTEM |
Windows |
|
WORKING TEMPERATURE |
-40-+70°C |
|
PRINTING HEAD LIFE |
100KM /100M Pulses |
|
WEIGHT |
Approx 642g |
|
REMARK |
Weather-proof |
1 : Fuel Dispensers, CNG Dispensers, ATMs, CDMs, Kiosk Terminals
2 : Payment Systems, Vending Machines, Gaming Machines, Parking Systems
