Quick Details
-
GPS:
-
L1C/A, L2C, L2E, L5
-
BeiDou:
-
B1I, B2I, B3I
-
Galileo:
-
E1, E5AltBOC ,E5A,E5B
-
GLONASS:
-
L1CA/L2C/L2P/L3/L5
-
Tilt survey:
-
60 degree
-
Display:
-
1.46-inch color capacitive OLED touch, resolution: 320*240
-
battery:
-
7.2V ,6800mah
-
Protocol:
-
GeoTalk,SATEL,PCC-GMSK,TrimTalk,TrimMark,SOUTH
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Guangdong, China
-
channels:
-
1408
-
GPS:
-
L1C/A, L2C, L2E, L5
-
BeiDou:
-
B1I, B2I, B3I
-
Galileo:
-
E1, E5AltBOC ,E5A,E5B
-
GLONASS:
-
L1CA/L2C/L2P/L3/L5
-
Tilt survey:
-
60 degree
-
Display:
-
1.46-inch color capacitive OLED touch, resolution: 320*240
-
battery:
-
7.2V ,6800mah
-
Protocol:
-
GeoTalk,SATEL,PCC-GMSK,TrimTalk,TrimMark,SOUTH
Technical parameter
|
System Configuration
|
|
Environmental Performance
|
|
|||
|
Operating system
|
Linux
|
Operating temperature
|
-30℃ ~ +65℃
|
|||
|
Built-in storage
|
8GB, supports MicroSD storage expansion
|
Storage Temperature
|
-40℃ ~ +80℃
|
|||
|
Bluetooth
|
V2.1 + EDR/V4.0 dual-mode, CIass2
|
Waterproof and dustproof
|
IP68
|
|||
|
WIFI
|
802.11b/g/n
|
UHF radio station
|
Built-in receiving station
External launch: |
|||
|
Voice
|
TTS voice broadcast
|
Operating frequency:
|
410-470mhz
|
|||
|
Electron bubble
|
Support
|
|
|
|||
|
Satellite Characteristics
|
|
|
|
|||
|
Satellite Channel
|
1408
|
GLONASS
|
G1P1，G2P2，G1OC，G2OC，G3OC
|
|||
|
BDS-2
|
B1i、B2i、B3i
|
Galileo
|
E1BC、E5a，E5b，E5ALTBOC、E6BC
|
|||
|
BDS-3
|
B1C、B2a、B2b、ACEBOC
|
QZSS
|
L1CA，L2C，L5，L1C，LEX
|
|||
|
GPS
|
L1C/A，L1C，L1P(Y)，L2C，L2P（Y），L5
|
L-Band
|
Support
|
|||
|
Inertial navigation IMU
|
|
|
|
|||
|
Tilt measurement
|
Supported
|
Tilt accuracy
|
60 °/2cm (horizontal)
|
|||
|
Power supply characteristics
|
|
Physical indicators
|
|
|||
|
Battery capacity
|
7.2V 6900mAh
|
Weight
|
0.92kg
|
|||
|
External Power Supply
|
9-28VDC with overvoltage protection
|
Size
|
160mm*68
mm
|
|||
