Quick Details
-
Jacket:
-
PVC
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Huadong
-
Model Number:
-
4 core armoured cable 120mm
-
Voltage:
-
0.6/1KV, 8.7/10kv,35kv
-
Standard:
-
IEC 60502
-
Conductor:
-
aluminum cable
-
Conductor Screen:
-
Seim-conductive
-
Insulation:
-
XLPE/ LSZH
-
Armoured:
-
Steel wire or Stee tape
-
Sheath:
-
PVC/ LSZH
-
Cores:
-
Single Core, Three core
-
Cross-section:
-
95mm, 50 sq mm copper cable
-
240mm xlpe 4 core armoured cable prices:
-
1.2~20 USD
Quick Details
-
Insulation Material:
-
Xlpe
-
Application:
-
Power Station
-
Conductor Material:
-
Copper
-
Jacket:
-
PVC
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Huadong
-
Model Number:
-
4 core armoured cable 120mm
-
Voltage:
-
0.6/1KV, 8.7/10kv,35kv
-
Standard:
-
IEC 60502
-
Conductor:
-
aluminum cable
-
Conductor Screen:
-
Seim-conductive
-
Insulation:
-
XLPE/ LSZH
-
Armoured:
-
Steel wire or Stee tape
-
Sheath:
-
PVC/ LSZH
-
Cores:
-
Single Core, Three core
-
Cross-section:
-
95mm, 50 sq mm copper cable
-
240mm xlpe 4 core armoured cable prices:
-
1.2~20 USD
1. aluminum cable 120mm xlpe 4 core armoured cable application:
Fire-resistant XLPE Insulation PVC sheah power cable is used indoor or outdoor, in tunnel, cable furrow or pipe.
1, Cross-section area can be up to 800sq.mm(copper or aluminum conductor)
2, Conductor long-time operating temperature is 90 degrees.
3, In short circuit conductor highest temperature should be not more than 250 degree
2. aluminum cable 120mm xlpe 4 core armoured cable Description:
Standard: IEC 60502
Conductor: Cu/ Aluminum
Conductor Screen: Semi-conductive
Insulation: XLPE(Cross-linked Polyethylene)
Insulation Screen: Semi-conductive
Armour: Steel Wire/ Steel Tape Armoured
Sheath: PVC or LSZH
Sheath color: Black
Bending Radius:
Single core: 20D±0.05, multi-core: 15D ±0.05
3. aluminum cable 120mm xlpe 4 core armoured cable sheet :
|
1st class |
0.6/1 |
1.8/3 |
3.6/6 |
6/10 |
8.7/15 |
12/20 |
18/30 |
21/35 |
|||
|
2nd cl ass |
1/1 |
3/3 |
6/6 |
8.7/10 |
12/15 |
18/20 |
- |
26/35 |
||||
|
1 Core |
Section area(mm2) |
1.5-800 |
25-800 |
25-800 |
25-800 |
35-800 |
50-800 |
50-800 |
50-800 |
|||
|
2 Core |
Section Area(mm2) |
1.5-185 |
/ |
/ |
/ |
/ |
/ |
/ |
/ |
|||
|
3 Core |
Section area(mm2) |
1.5-400 |
25-400 |
25-400 |
25-400 |
35-400 |
50-400 |
50-400 |
50-400 |
|||
|
4 Core |
Section Area(mm2) |
2.5- 400 |
25-400 |
/ |
/ |
/ |
/ |
/ |
/ |
|||
|
5 Core |
Section area(mm2) |
2.5-400 |
25-400 |
/ |
/ |
/ |
/ |
/ |
/ |
aluminum cable 120mm xlpe 4 core armoured cable packging:
1.Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2.By standard wooden drum or roll.
3.Drum size:1100mm*1100mm*1100mm or as your reques
aluminum cable 120mm xlpe 4 core armoured cable:
Advanced connectors & assembly cables machines and testing equipments.
Large production capacity, short delivery.
Strict QC checking before delivery.
OEM/ODM service available, help you on designing.
Prompt quotation for your inquiry.
More than 10 years experiences in cable and wire field.
Professional connector and cable manufacturer, with good quality and competitive price.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!
