Quick Details
-
Place of Origin:
-
China
-
Model Number:
-
JIEKE
-
Battery:
-
60V 12AH/20AH Lithium Battery
-
Tire:
-
3.0-10
-
Range:
-
60-80km
-
Top speed:
-
38-48km/h
-
Brake:
-
Disc
-
Loading capacity:
-
180kgs/396Ibs
-
Frame:
-
Steel Material
-
Product size:
-
1756x750x700mm
-
Light:
-
LED
-
Display:
-
Digital Display
Quick Details
-
Displacement:
-
100-200CC
-
Max. Speed:
-
61 - 80km/h
-
Brand Name:
-
MADEFOR
-
Place of Origin:
-
China
-
Model Number:
-
JIEKE
-
Battery:
-
60V 12AH/20AH Lithium Battery
-
Tire:
-
3.0-10
-
Range:
-
60-80km
-
Top speed:
-
38-48km/h
-
Brake:
-
Disc
-
Loading capacity:
-
180kgs/396Ibs
-
Frame:
-
Steel Material
-
Product size:
-
1756x750x700mm
-
Light:
-
LED
-
Display:
-
Digital Display
|
ENGINE TYPE
|
139QMB
|
|
Displacement
|
49.5ml
|
|
Engine
|
1 Cylinder, 4 Stroke
|
|
Bore & Stroke
|
39×41.5
|
|
Cooling System
|
Air Cooled
|
|
Compression Ratio
|
10.5:1
|
|
Fuel feed
|
90#
|
|
Max Power( Kw/rpm)
|
2.4/7500
|
|
Max Torque(N.M/rpm)
|
3.1/6500
|
|
Max Speed
|
65kmph
|
|
Ground clearance
|
105mm
|
|
Fuel consumption
|
1.8L/100KM
|
|
Drive Train
|
CVT
|
|
Ignition
|
CDI
|
|
Transmission
|
Belt
|
|
Fuel tank capacity
|
5L
|
|
Starting System
|
Electric+kick start
|
|
Front Brakes
|
Disc brake
|
|
Rear Brake
|
Drum brake
|
|
Front suspension
|
2 Hydraulic Suspension
|
|
Rear suspension
|
2 Hydraulic Suspension
|
|
Front wheels
|
350-10
|
|
Rear wheels
|
350-10
|
|
Wheel Base
|
1210 mm
|
|
Seat Height
|
740 mm
|
|
Payload
|
150kg
|
|
Net Weight
|
77kg
|
|
Gross Weight
|
97kg
|
|
vehicle size
|
1730*680*1050
|
|
Packing type
|
Steel + Carton
|
|
Packing size
|
1700*455*830
|
|
20' container
|
32units-SKD
|
|
40' HQ container
|
105units-SKD
|
