Quick Details
-
Power:
-
55.4KW/2200
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HY
-
Machine Weight:
-
7650 kg
-
Product name:
-
Excavator
-
Hydraulic parts:
-
Famous Brand Hydraulic Parts
-
Capacity:
-
5 Ton Truck Crane
-
Color:
-
Customers Optional
-
MOQ:
-
1 unit
-
Certificate:
-
ISO CE
-
Usage:
-
Construction Lifting
-
Rotation Angle:
-
360 Degree
-
Installation space:
-
900 mm
-
High quality:
-
Mobile Crane Lifting Capacity
Quick Details
-
Operating Weight:
-
7TON, 6TON, 13Ton, 22Ton
-
Bucket capacity:
-
0.32m³/0.55m³/1.05m³
-
Engine Brand:
-
Kubota
-
Power:
-
55.4KW/2200
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HY
-
Machine Weight:
-
7650 kg
-
Product name:
-
Excavator
-
Hydraulic parts:
-
Famous Brand Hydraulic Parts
-
Capacity:
-
5 Ton Truck Crane
-
Color:
-
Customers Optional
-
MOQ:
-
1 unit
-
Certificate:
-
ISO CE
-
Usage:
-
Construction Lifting
-
Rotation Angle:
-
360 Degree
-
Installation space:
-
900 mm
-
High quality:
-
Mobile Crane Lifting Capacity
Product Description
Specification
|
Model
|
Kubota V3307T
|
|
Type
|
Water-cooling. turbo charging
|
|
Quantity of cylinders
|
4
|
|
Bore x stroke (mm)
|
94 x 120
|
|
Displacement (L)
|
3.3L
|
|
Power output (KW/rpm)
|
48.9/2000
|
|
Maximum torque (NM/rpm)
|
263.1/1400
|
|
Minimum ground clearance (mm)
|
385
|
|
Operating weight (t)
|
7.65
|
|
Ground pressure (kPa)
|
34
|
|
Overall length (mm)
|
6240
|
|
Overall height (mm)
|
2680
|
|
Overall width (mm)
|
2260
|
|
Pump
|
Imported
|
|
Type
|
Variable piston pump
|
|
Maximum discharge flow (L/min)
|
160
|
|
Control circuit (MPa)
|
3.5
|
|
Travel circuit (MPa)
|
28
|
|
Swing circuit (MPa)
|
23.5
|
|
Travel motor
|
Variable axial piston motor
|
|
Travel brakes
|
Lubricated double-disc
|
|
Parking brake
|
Pressure release
|
|
Fuel tank (L)
|
120
|
|
Cooling system (L)
|
11
|
|
Engine oil (L)
|
11
|
|
Hydraulic oil tank (L)
|
140
|
Packing & Delivery
Waxed before delivery by container or RO-RO or bulk ship
