Perfect Laser 10W High Accuracy Desktop Mini Co2 Laser Engraving Machine Cutter DIY

Perfect Laser 10W High Accuracy Desktop Mini Co2 Laser Engraving Machine Cutter DIY

FOB Reference Price: Get Latest Price

≥1 Sets

US $2000

≥5 Sets

US $1800

≥10 Sets

US $1500

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Graphic Format Supported:: DXF, BMP, svg, png, jpg, jpeg,

Cooling Mode:: Air Cooling

Place of Origin:: Hubei, China

Brand Name:: Perfect Laser

Weight (KG):: 6.3 KG

Machinery Test Report:: Provided CE certificate

Core Components:: Laser source

Spot Size:: 0.06mm

Document Format:: svg, png, jpg, jpeg,bmp, dxf

Laser power:: 10W

Operating Software:: LaserGRBL,LightBurn

Support Systems:: Windows/MacOS

Laser Wavelength:: 445±5nm

Model:: PEDK-20

Engraving Accuracy:: 254 dpi

Support material:: leather,acrylic,metal paint surface,nodized surface,

Quick Details

Engraving Area:: 400*415mm, 400*415mm

Laser Type:: Semiconductor

Engraving Speed:: 0-10000mm/min

Graphic Format Supported:: DXF, BMP, svg, png, jpg, jpeg,

Cooling Mode:: Air Cooling

Place of Origin:: Hubei, China

Brand Name:: Perfect Laser

Weight (KG):: 6.3 KG

Machinery Test Report:: Provided CE certificate

Core Components:: Laser source

Spot Size:: 0.06mm

Document Format:: svg, png, jpg, jpeg,bmp, dxf

Laser power:: 10W

Operating Software:: LaserGRBL,LightBurn

Support Systems:: Windows/MacOS

Laser Wavelength:: 445±5nm

Model:: PEDK-20

Engraving Accuracy:: 254 dpi

Support material:: leather,acrylic,metal paint surface,nodized surface,

Perfect Laser 10W High Accuracy Desktop Mini Co2 Laser Engraving Machine Cutter DIY

Model : PEDK-20

Contact: Spring Whatsapp: + 86 136 5988 6778 Email: sales011@perfectlaser.net

Production Introduction

Perfect Laser PEDK-20 co2 laser engraving machine is simple to operate and can support offline operation, no computer online. The engraving machine supports the creation of multiple software, multiple formats and various materials. The mini laser cutter engraver with a larger size of 400*415mm, providing customers with more widely creative space.Ultra-high accuracy 0.06mm and a new upgrade with 10W power brings you a rich creation experience.

Sample & Application

Machine Details

Feature of 10W Desktop High Accuracy Large Format Laser Engraving Machine

1. The wood laser engraving machine using multi-lens laser combination scheme, the spot is compressed to 0.06mm ultra-high precision, and the carving details are more abundant.
2. The 10w laser module is more powerful, the beam Rayleigh length is longer, the penetration is stronger, and it is easy to cut thicker materials.The wood laser engraving machine can carve a variety of hard object surface.
3. Large size workingarea, large format works can be created without multiple carving, once can be achieved, it also can be optional to adjust the height columnup to 150mm.
4. Support multiple software, multiple formats and multiple materials.
5. Under the offline working condition, the control of the wood laser engraving machine can be realized by one key. With the breathing lamp, the working state of the machine is clear at a glance, and it is more interactive.
6. 60% of the components are modular and support fast assembly.
7. The desktop laser engraving machine diy adopts dual stepping motors, built-in 32-bit main control chip, mute main board, and self-developed algorithm to precisely control the left and right Y-axis movements, and the running trajectory is highly synchronized, making the operation more stable.

Technical Data

Product Name	10W Desktop High Accuracy Large Format Laser Engraving Machine PEDK-20
Spot Size	0.06mm
Carving Depth	0-10mm
Cutting Thickness	0-18mm
Laser Wavelength	455±5nm
Laser Power	10W
Carving Accuracy	254 dpi
Carving Speed	MAX 10000mm/min
Carving area	400*415mm
Light Source	semiconductor laser
Input voltage	100~240V 50~60 Hz
Output Voltage	DC 24.0V 3.0A
Operating System	Windows/Mac OS
Format	gcode(after slicing)
Slice File Format	svg, png, jpg, jpeg,bmp, dxf
Slice Software	LaserGRBL，LightBurn
Application Materials	plastic, matte stainless steel, metal paint surface, anodized surface, electrophoretic surface, dark metal surface, etc
