Quick Details
-
Panel Size:
-
300mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
Bar counter logo P2-1R1G1B
-
Product Name:
-
circle logo screen, Led Logo Display
-
Pixel pitch:
-
2mm
-
Module resolution:
-
150 dots X 150 dots
-
LED chip:
-
San an
-
Display density:
-
250000 dots/㎡
-
Grayscale level:
-
12bits-16bits
-
Loss of control points:
-
≤ 1 in 10,000
-
Optimal viewing distance:
-
≥3M away
-
Device drive:
-
1/50 scan
-
Control mode:
-
NOVA TCC70A
Quick Details
-
Application:
-
Indoor
-
Brand Name:
-
OEM
-
Color:
-
FULL COLOR
-
Panel Size:
-
300mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
Bar counter logo P2-1R1G1B
-
Product Name:
-
circle logo screen, Led Logo Display
-
Pixel pitch:
-
2mm
-
Module resolution:
-
150 dots X 150 dots
-
LED chip:
-
San an
-
Display density:
-
250000 dots/㎡
-
Grayscale level:
-
12bits-16bits
-
Loss of control points:
-
≤ 1 in 10,000
-
Optimal viewing distance:
-
≥3M away
-
Device drive:
-
1/50 scan
-
Control mode:
-
NOVA TCC70A
Product Paramenters
|
Pixel point composition
|
1 red, 1 green, 1 blue LED (SMD1515)
|
|
Module size
|
Diameter 300mm
(finished display diameter 300mm, finished frame diameter 340mm)
|
|
Maximum white balance brightness
|
600cd/㎡
|
|
Display color
|
≥16.7M kinds, maximum 281 trillion kinds
|
|
Viewable angle
|
Horizontal: ≥120° vertical ≥120°
|
|
Brightness adjustment
|
256 levels of software adjustment, 16 levels of automatic adjustment
|
|
Ambient temperature and humidity
|
Temperature: -20℃～+60℃, Humidity: 10%-95%
|
|
Power consumption (maximum/average)
|
About 100W/set
|
|
Flatness
|
Adjacent image degree between ≤ 0.5mm; module splicing gap ≤ 0.5mm
|
|
Frame change frequency
|
≥60HZ
|
|
Refresh frequency
|
3840HZ
|
|
Screen life
|
≥100,000 hours.
|
|
Continuous working time
|
＞72 hours
|
|
Average trouble-free time
|
＞1,000hours
|
|
Working voltage
|
AC220V±15%, 50Hz±2 Hz
|
|
Weight of screen body
|
4Kg/set
|
|
Control system
|
Cloud platform, USB, Wifi, 4G
|
Applications
Applications for Company/ Store LOGO,Art gallery ,Exhibition, Chain store, Airport, Clubs,Restaurant and Hotel, Subway
