1. Opening width: 600-1400mm,
2. 2 panels center opening or side opening 800-1400mm,
3. 3 panels side opening 700-1800mm,
4. 4 panels center opening 2000-3000mm
4. 4 panels center opening 2000-3000mm
5. 6 panels center opening
6. Opening height: 2000mm or 2100mm
Motor:
1. AC induction motor can use vector control and VVVF control. If VVVF control adopted, speed sensor would be not necessary. The method of control is simple, meanwhile, same controller can drive several similar motors.
2. Vector control, AC induction motor only needs speed information, angle information are not necessary. Therefore, encoder only adopts increment. Besides, AC induction motor operates without initial position, during application of door system, not necessary to study pole position and absolute encoder.
3. AC induction motor has no demagnetization problem. AC motor stall torque is rather big, can be applied to more door types.
Controller:
1. The method of control is simple, same controller can drive several similar motors.
2. It is applicable to door open
width with heavy load.
width with heavy load.
Door Panel Finish:
1. Door panel finish: painted, stainless steel(hairline, mirror, etching)
