Quick Details
-
Brand Name:
-
HECHA
-
Fork Length:
-
1500mm
-
Fork Width:
-
180mm
-
Overall Dimensions:
-
4730*2340*2850
-
Weight (KG):
-
15230 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE
-
Spare Parts Service:
-
Provided
Quick Details
-
Min. Lifting Height:
-
2850mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
HECHA
-
Fork Length:
-
1500mm
-
Fork Width:
-
180mm
-
Overall Dimensions:
-
4730*2340*2850
-
Weight (KG):
-
15230 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Certification:
-
CE
-
Spare Parts Service:
-
Provided
|
Distinguishing
mark |
1.1 | Manufacturer (abbreviation) | HECHA | ||||||
| 1.2 | Manufacturer's type designation | CPCD120N-MG3 | CPCD120N-MW3 | CPCD140N-MG3 | CPCD140N-MW3 | CPCD160N-MG3 | CPCD160N-MW3 | ||
| 1.3 | Drive: electric (battery or mains), diesel, petrol, fuel gas | Diesel | |||||||
| 1.4 | Operator type: hand, pedestrian, standing, seated, order-picker | Seated | |||||||
| 1.5 | Rated capacity/rated load | Q (kg) | 12000 | 14000 | 16000 | ||||
| 1.6 | Load centre distance | c (mm) | 600 | 600 | 600 | ||||
| 1.8 | Load distance, centre of drive axle to fork | x (mm) | 760 | 785 | 800 | ||||
| 1.9 | Wheelbase | y (mm) | 3000 | 3000 | 3000 | ||||
| Weight | 2.1 | Service Weight | kg | 15600 | 17600 | 19200 | |||
| Tyres, chassis | 3.1 | Tyres: solid rubber, superelastic, pneumatic, polyurethane | Pneumatic | ||||||
| 3.2 | Tyre size, front | 10.00-20-14PR | 11.00-20-18PR | 12.00-20-20PR | |||||
| 3.3 | Tyre size, rear | 10.00-20-14PR | 11.00-20-18PR | 12.00-20-20PR | |||||
| 3.6 | Tread, front | b 10 (mm) | 1800 | 1800 | 1800 | ||||
| 3.7 | Tread, rear | b 11 (mm) | 1920 | 1890 | 1890 | ||||
| Dimensions | 4.1 | Tilt of mast/fork carriage forward/backward | α/β(°) | 6/12 | 6/12 | 6/12 | |||
| 4.2 | Height, mast lowered | h 1 (mm) | 3180 | 3270 | 3290 | ||||
| 4.4 | Lift | h 3 (mm) | 3000 | 3000 | 3000 | ||||
| 4.7 | Height of overhead guard (cabin) | h 6 (mm) | 2910(3050) | 2940(3080) | 2960(3100) | ||||
| 4.19 | Overall length | l 1 (mm) | 6000 | 6210 | 6320 | ||||
| 4.20 | Length to face of forks | l 2 (mm) | 4500 | 4710 | 4820 | ||||
| 4.21 | Overall width | b 1 (mm) | 2420 | 2490 | 2490 | ||||
| 4.22 | Fork dimensions ISO 2331 | s/e/l (mm) | 1500x200x80 | 1500x200x85 | 1500x200x90 | ||||
| 4.25 | Distance between fork-arms | b 5 (mm) | 520/2200 | 520/2200 | 520/2200 | ||||
| 4.31 | Ground clearance, laden, below mast | m 1 (mm) | 250 | 250 | 270 | ||||
| 4.32 | Ground clearance, centre of wheelbase | m 2 (mm) | 315 | 330 | 350 | ||||
| 4.35 | Turning radius | W a (mm) | 4150 | 4350 | 4450 | ||||
| Performance data | 5.1 | Travel speed, laden/unladen | km/h | 26/28 | 24/29 | 25/30 | |||
| 5.2 | Lift speed, laden/unladen | m/s | 0.35/- | 0.35/- | 0.33/- | ||||
| 5.3 | Lowering speed, laden/unladen | m/s | 0.35/- | 0.35/- | 0.33/- | ||||
| 5.5 | Drawbar pull, laden/unladen | N | 100000/- | 100000/- | 100000/- | ||||
| 5.7 | Gradeability, laden/unladen | % | 20/- | 20/- | 20/- | ||||
| 5.10 | Service brake | Pneumatic Drum | Pneumatic Drum | Pneumatic Drum | |||||
| Parking brake | Spring energy storage | Spring energy storage | Spring energy storage | ||||||
|
Combustion-
engine |
7.1 | Engine manufacturer/type | CHINA/YC6B160Z-T21 | CUMMINS/QSB6.7-C160 | CHINA/YC6B160Z-T21 | CUMMINS/QSB6.7-C160 | CHINA/6BTAA5.9-C160 | CUMMINS/QSB6.7-C160 | |
| Emission STD | Stage3A/Tier3 | Stage3A/Tier3 | Stage3A/Tier3 | ||||||
| 7.2 | Engine power according to DIN ISO 1585 | kw | 115 | 119 | 115 | 119 | 118 | 119 | |
| 7.3 | Rated speed | min | 2300 | 2300 | 2300 | 2300 | 2200 | 2300 | |
| 7.4 | Number of cylinders/displacement | (-)/(cm 3 ) | 6/- | ||||||
| 7.10 | Battery voltage/nominal capacity | V/Ah | 2x12/120 | ||||||
| Rated torque | N.m/r/min | 560/1500 | 731/1500 | 560/1500 | 731/1500 | 670/1500 | 731/1500 | ||
| Bore x stroke | mm | 108x125 | 107x124 | 108x125 | 107x124 | 108x125 | 107x124 | ||
| Stage FWD/RVS | 2/1 | ||||||||
| Addition data | 10.1 | Operating pressure for attachments | bar | 200 | |||||
