Quick Details
-
Size:
-
12500*2500*2550mm
-
Place of Origin:
-
Shandong, China
-
Product name:
-
fence semi trailer
-
Function:
-
Cargo Transport
-
Dimension:
-
12500*2500*1550mm
-
Suspension:
-
Leaf Spring Suspension
-
Axle:
-
13 Ton FUWA Brand
-
Landing Gear:
-
Standard 28Ton
-
Color:
-
Customer's Requirement
-
Tire:
-
12R22.5
-
King pin:
-
2"(50mm)or3.5"(90mm)
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
50Ton
-
Brand Name:
-
Chengda
-
Size:
-
12500*2500*2550mm
-
Place of Origin:
-
Shandong, China
-
Product name:
-
fence semi trailer
-
Function:
-
Cargo Transport
-
Dimension:
-
12500*2500*1550mm
-
Suspension:
-
Leaf Spring Suspension
-
Axle:
-
13 Ton FUWA Brand
-
Landing Gear:
-
Standard 28Ton
-
Color:
-
Customer's Requirement
-
Tire:
-
12R22.5
-
King pin:
-
2"(50mm)or3.5"(90mm)
Aluminum Trailer Cargo Trailer Enclosed Fiberglass Cargo Trailer for Sale
Product Description
Mainly suitable for medium and long-distance transportation of medium, heavy and bulk cargo, with strong applicability, the first choice for medium and long-distance freight vehicles.
Specification
|
Proution name
|
fence semi trailer
|
|
Overall Dimensions（L x W x H）(mm)
|
12500x2500x2550
|
|
Cargo box dimension (L x W x H)(mm)
|
12000X2300X600
|
|
Loading capacity(KG)
|
50000
|
|
Tare Weight(KG)
|
6550
|
|
Total Weight(KG)
|
56350
|
|
Main beam
|
The height of the beam is 500 mm, upper plate is14mm,down plate is 16mm, middle plate is 8 mm
material:Q345B |
|
Side beam
|
Q235 16# channel steel
|
|
Platform plate
|
3mm Diamond plate
|
|
Axle
|
13Ton, Fuwa brand option one hundred fifty thousand Kilometers no need maintenance
|
|
Tires
|
12R22.5, 12 pcs. Taitong brand
|
|
Rim
|
9.0*22.5 steel disc wheel, 10 holes ISO, 12 pcs
|
|
King pin
|
2” and 3.5” removable Kingpin, bolted in type 500mm from the front face of the front bolster
|
|
Landing gear
|
28 ton single action supporting legs
|
|
Suspension
|
Mechanical Leaf Spring Suspension
|
|
Steel spring
|
10/10/10 leaf spring suspension
|
|
Wheel base
|
7450+1310+1310
|
|
Spare tire carriers
|
2 pieces
|
|
Brake
|
Standard
|
|
Tool box
|
1 piece
|
|
Voltage
|
24V
|
|
Air chamber
|
Six double air chamber
|
|
Painting
|
According to the requirement of the buyer.
|
Details Images
Customers Feedback
Packing & Delivery
For the flatbed semi trailer cut the rear part then put inside 40ft HQ container which can save a lot of freight, this method is very popular for transport the flatbed trailer but when you receive the trailer you need to welded them together so if you choose this method need to confirm whether you can arrange welded them after the container arrived.
Shipping by container
Shipping by bulk shippment
S
hipping by Ro-ro
