Quick Details
-
Color:
-
FULL COLOR
-
Panel Size:
-
640*480mm, 640*480mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FI2W
-
Product name:
-
Led Panels Display Shenzhen Indoor Set Fixed Full Color Cabinet
-
Cabinet size:
-
640*480mm
-
Cabinet material:
-
Die-casting Alumium
-
Brightness:
-
1000cd/sqm
-
Refresh rate:
-
3840Hz
-
Keyword:
-
LED Video Wall Panel Pric
-
Certificate:
-
CE ROHS FCC CCC ISO9001
-
Life span:
-
100000hours
-
Warranty:
-
5 Years
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
CANBEST
-
Color:
-
FULL COLOR
-
Panel Size:
-
640*480mm, 640*480mm
-
Place of Origin:
-
Henan, China
-
Model Number:
-
FI2W
-
Product name:
-
Led Panels Display Shenzhen Indoor Set Fixed Full Color Cabinet
-
Cabinet size:
-
640*480mm
-
Cabinet material:
-
Die-casting Alumium
-
Brightness:
-
1000cd/sqm
-
Refresh rate:
-
3840Hz
-
Keyword:
-
LED Video Wall Panel Pric
-
Certificate:
-
CE ROHS FCC CCC ISO9001
-
Life span:
-
100000hours
-
Warranty:
-
5 Years
Warranty
Technical Parameters
|
Model
|
FIW125
|
FIW186
|
FI2W
|
|
LEDType
|
SMD1515
|
SMD1515
|
SMD1515
|
|
Physical Density (dot/m²)
|
640000
|
289050
|
160000
|
|
Module Size (W ×H ×D) mm
|
320x160x17
|
320x160x17
|
320x160x17
|
|
Module Resolution(W×H)
|
256x128
|
172x86
|
128x64
|
|
Cabinet Size (W ×H ×D) mm
|
640x480x74
|
640x480x74
|
640x480x74
|
|
Cabinet Material
|
Die Casting Aluminum
|
Die Casting Aluminum
|
Die Casting Aluminum
|
|
Scanning Mode
|
1/64
|
1/48
|
1/32
|
|
Cabinet Flatness(mm)
|
≤0.10
|
≤0.10
|
≤0.10
|
|
Grey Scale (Bit)
|
14
|
14
|
14
|
|
Protection Level
|
IP45
|
IP45
|
IP45
|
|
Brightness(cd/㎡)
|
500-900cd/㎡
|
500-900cd/㎡
|
500-900cd/㎡
|
|
ColorTemperature
|
3200-9300Kadjustable
|
3200-9300Kadjustable
|
3200-9300Kadjustable
|
|
Brightness Uniformity
|
≥98%
|
≥98%
|
≥98%
|
|
Horizontal/Vertical ViewAngle
|
≥140°/≥120°
|
≥140°/≥120°
|
≥140°/≥120°
|
|
Contrast Ratio
|
≥5000:1
|
≥5000:1
|
≥5000:1
|
|
Module Input Voltage DC
|
5V
|
5V
|
5V
|
|
Max Refresh Rate
|
≥3840Hz
|
≥3840Hz
|
≥3840Hz
|
|
Input VoltageAC
|
110-220V
|
110-220V
|
110-220V
|
|
Cabinet Max Power Consumption
|
≤600W/m2
|
≤580W/m2
|
≤480W/m2
|
|
Cabinet Aver.PowerConsumption
|
≤200W/m2
|
≤180W/m2
|
≤160W/m2
|
|
Working Temperature
|
20℃～+80℃
|
20℃～+80℃
|
20℃～+80℃
|
|
Working Humidity
|
10%～95%RH
|
10%～95%RH
|
10%～95%RH
|
|
Installation/Service Method
|
Front installation/Front service
|
Front installation/Front service
|
Front installation/Front service
|
