Quick Details
-
Model Number:
-
L5024+M124
-
Function:
-
NIGHT VISION
-
Size:
-
7-inch TFT LCD screen
-
Image resolution:
-
1024x600
-
Special Features:
-
Touch screen operation
-
Feature:
-
Built-in microphone and speaker
-
Warranty:
-
2 Years
-
Indoor monitor:
-
Intercom Calling
-
Support:
-
Motion detection
Quick Details
-
Resolution:
-
1080P
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ANNKE
-
Model Number:
-
L5024+M124
-
Function:
-
NIGHT VISION
-
Size:
-
7-inch TFT LCD screen
-
Image resolution:
-
1024x600
-
Special Features:
-
Touch screen operation
-
Feature:
-
Built-in microphone and speaker
-
Warranty:
-
2 Years
-
Indoor monitor:
-
Intercom Calling
-
Support:
-
Motion detection
Product Description
Key features
★2MP full HD camera
★FOV 129° horizontal
★Noise reduction, including echo filtering
★Audio support (built-in microphone and speaker)
★Waterproof grade IP65
★4x alarm input
★Configurable via internet
★WIFI and LAN connection
★7-inch TFT LCD screen
★Image resolution of 1024×600
★Touch screen operation
★Network connection via LAN 10/100Mbps
★RJ45 connector on the bottom of the back
★Standard Wi-Fi 802.11b/g/n (Wi-Fi quality is locally dependent)
★Built-in microphone and speaker
★Audio with noise reduction and echo filtering
★Power supply via PoE (IEEE802.3af)/12V DC
★SD card supported up to 32GB
★8x alarm input and 2x alarm output
Specification
|
Camera
|
Image Sensor
|
1/3" Progressive Scan CMOS
|
|
|
Video Resolution
|
2MP HD camera
|
|
|
Signal System
|
PAL/NTSC
|
|
|
Video Compression
|
H.264
|
|
|
Stream
|
Main stream: 1080p@30fps, 720p@25fps
Sub stream: D1@25fps |
|
|
Video Bitrate
|
64Kbps
|
|
|
Lens
|
2.8 mm
|
|
|
Angle of View
|
Horizontal: 129° Vertical: 75°
|
|
|
DNR
|
3D DNR
|
|
|
Wide Dynamic Range
|
True WDR
|
|
|
IR-Cut Filter
|
Yes
|
|
|
Audio intercom
|
Two-way audio communication
|
|
|
Audio input
|
Built-in omnidirectional microphone
|
|
|
Audio output
|
Built-in loudspeaker
|
|
|
Audio quality
|
Noise suppression and echo cancellation
|
|
|
Network protocol
|
TCP/IP, RSTP
|
|
|
Wired network
|
10/100 Mbps Ethernet
|
|
|
Power supply
|
IEEE802.3af, standard PoE
12 VDC |
|
|
RS-485
|
1
|
|
|
Alarm input
|
4
|
|
|
Debugging port
|
1
|
|
|
Grounding
|
1
|
|
|
TAMPER switch
|
1
|
|
|
Power consumption
|
＜ 10 W
|
|
|
Working temperature
|
,-40° C to 53° C(-40° F to 127.4° F)
|
|
|
Protection leve
|
IP65
|
|
|
Dimension
|
38 mm × 65 mm × 27 mm
|
|
Monitor
|
Display screen
|
7-inch colorful TFT screen
|
|
|
Display resolution
|
1024 × 600
|
|
|
Operation method
|
Capacitive touch screen
|
|
|
Audio input
|
Built-in omnidirectional microphone
|
|
|
Audio output
|
Built-in loudspeaker
|
|
|
Audio quality
|
Noise suppression and echo cancellation
|
|
|
Network protocol
|
TCP/IP, RSTP
|
|
|
Wired network
|
10/100 Mbps Ethernet
|
|
|
Wireless network
|
Wi-Fi 802.11 b/g/n
|
|
|
RS-485
|
1 RJ-45 10/100 Mbps self-adaptive
|
|
|
RS-485
|
1
|
|
|
Alarm input
|
8-ch alarm inputs
|
|
|
Relay output
|
2
|
|
|
TF card
|
Max to 32 G, SD 2.0 or lower version
|
|
|
Power consumption
|
＜ 6W
|
|
|
Working temperature
|
,-10 °C to 55 °C (14 °F to 131 °F)
|
|
|
Dimension
|
200 mm × 140 mm × 15.1 mm (7.9"× 5.5" × 0.6")
|
