Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
URAYZERO
-
Model Number:
-
GH24V2KW
-
Input Voltage:
-
12VDC
-
Output Voltage:
-
230VAC
-
Output Current:
-
13A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
357*273*95mm
-
Certificate:
-
CE/Rohs/ISO/IEC
-
Warranty:
-
1 Year
-
Weight:
-
5.6kg/6.3kg
-
Application:
-
Off-grid Solar Power System
-
Display:
-
LCD
-
Rated power:
-
3200VA/3000W
-
MPPT Efficiency:
-
98 %
-
Waveform:
-
Pure Sine Wave
-
Maximum PV Array Power:
-
2000W
-
Transfer Time:
-
10ms
-
Protection:
-
IP21
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
98%
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
URAYZERO
-
Model Number:
-
GH24V2KW
-
Input Voltage:
-
12VDC
-
Output Voltage:
-
230VAC
-
Output Current:
-
13A
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
357*273*95mm
-
Certificate:
-
CE/Rohs/ISO/IEC
-
Warranty:
-
1 Year
-
Weight:
-
5.6kg/6.3kg
-
Application:
-
Off-grid Solar Power System
-
Display:
-
LCD
-
Rated power:
-
3200VA/3000W
-
MPPT Efficiency:
-
98 %
-
Waveform:
-
Pure Sine Wave
-
Maximum PV Array Power:
-
2000W
-
Transfer Time:
-
10ms
-
Protection:
-
IP21
Products Description
|
Datesheet
|
GH12V1.2KW
|
|
GH24V2KW
|
|
|
|
|
||||
|
Battery Voltage
|
12VDC
|
|
24VDC
|
|
|
|
|
||||
|
Battery Type
|
Lithium/Lead-acid
|
|
|
|
|
|
|
||||
|
Inverter Output
|
|
|
|
|
|
|
|
||||
|
Rated Power
|
1200VA/1000W
|
|
2200VA/2000W
|
|
|
|
|
||||
|
AC Voltage Regulation
|
230VAC土5% @ 50/60Hz
|
|
|
|
|
|
|
||||
|
Surge Power
|
2000VA
|
|
4000VA
|
|
|
|
|
||||
|
Efficiency
|
＞93%
|
|
|
|
|
|
|
||||
|
Waveform
|
Pure sine wave
|
|
|
|
|
|
|
||||
|
Transfer Time
|
10ms typical,20ms Max
|
|
|
|
|
|
|
||||
|
Chargers
|
|
|
|
|
|
|
|
||||
|
Maximnum PV Array Power
|
1000W
|
|
2000W
|
|
|
|
|
||||
|
Maximum PV change current
|
50A
|
|
50A
|
|
|
|
|
||||
|
Maximum AC Charge Current
|
50A
|
|
50A
|
|
|
|
|
||||
|
Maximum Charging Current
|
100A
|
|
100A
|
|
|
|
|
||||
|
Battery
|
|
|
|
|
|
|
|
||||
|
Battery Voltage
|
12VDC
|
|
24VDC
|
|
|
|
|
||||
|
constant charing voltage
|
14.1VDC
|
|
28.2VDC
|
|
|
|
|
||||
|
Floated charing Voltage
|
13.5VDC
|
|
27VDC
|
|
|
|
|
||||
|
Physical
|
|
|
|
|
|
|
|
||||
|
Protection Degree
|
IP20
|
|
|
|
|
|
|
||||
|
Dimension (W/H/D ）
|
440*340*170mm
|
|
440*340*170mm
|
|
|
|
|
||||
|
Net Weight
|
8.1KG
|
|
8.1KG
|
|
|
|
|
||||
|
Operating Environment
|
|
|
|
|
|
|
|
||||
|
Humidity
|
5% to 95% Relative HumidityNon-condensing)
|
|
|
|
|
|
|
||||
|
Operating Temperature
|
-10 -50°C(14F- 122F)
|
|
|
|
|
|
|
||||
|
Storage Temperature
|
-15°C -60C(5F-140)
|
|
|
|
|
|
|
||||
·Overload/ Over temperature/ short circuit protection
·Smart battery charger design for optimized battery performance·Configurable input voltage range for home appliances and personal computers via LCD setting
·Configurable battery charging current based on applications via LCD setting
·Configurable AC/Solar Charger priority via LCD setting
·Smart battery charger design for optimized battery performance·Configurable input voltage range for home appliances and personal computers via LCD setting
·Configurable battery charging current based on applications via LCD setting
·Configurable AC/Solar Charger priority via LCD setting
