Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
UE
-
Model Number:
-
UE-LC598S
-
Warranty:
-
12 Months
Quick Details
-
Motor Power:
-
750W
-
Operating Pressure:
-
8-10Bar
-
Power Supply:
-
110V/220V/380V
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
UE
-
Model Number:
-
UE-LC598S
-
Warranty:
-
12 Months
Product Description
Product Description
Product Parameters
Product Parameters
|
Rim Diameter
|
14” - 26” inch
|
|
Rim width
|
1000 mm
|
|
Max wheel diameter
|
1600 mm
|
|
Hydraulic Power
|
130 - 150 bar
|
|
Hydraulic Station Motor Power
|
1.5KW 380V/3PH 50HZ
|
|
Main Shaft Motor Power
|
1.8KW 380V/3PH 50HZ
|
|
Noise
|
<75dB
|
|
Packing dimensions
|
2100x1650x930 mm
|
|
Net weight
|
561kg
|
|
Gross weight
|
739 kg
|
|
Loading in 20/40 Ft. container
|
6/14 sets
|
Features
Features
Description Concentrate on truck tire service for 15 years, non-stop improving,constantly chasing the development of trucks, take good care of the tire and rim just like a baby. Highlights 1.Adopted hydraulic control system, reliable rim clamping, move stable.Hydraulic pump station adopted imported components with good stability . 2.Meet CE requirement, totally safe during operation. 3.Lifting arm cylinder is center supported , bear pressure average. 4.Movable operating station can be fully observed during operation to prevent danger by misoperation. 5.The gearbox is made of aluminum alloy die casting, with light weight,beautiful appearance, high intensity and good sealing performance. 6.The electric cabinet adopted CE level protection standard. 7.Lifting arm and the base are made of strengthened and thickened metal, with high intensity. 8.Lifting arm cylinder equipped safety protection device to increase the safety of operation.
