Quick Details
-
Fork Length:
-
1220mm
-
Fork Width:
-
140mm
-
Overall Dimensions:
-
3240*1500*2380mm
-
Weight (KG):
-
6000 kg
-
Model:
-
JG-T35A
-
Key words:
-
Hydraulic lift four wheel drive forklift
-
Product Type:
-
all rough terrain forklifts
-
Lifting height:
-
3m~ 6m
-
Engine:
-
Weichai490
-
Power:
-
40kw
-
Warranty::
-
1 Year
-
Loading Capacity:
-
3500kg
-
Transmission:
-
Electronic Hydraulic Transmisson
-
Drive mode:
-
4wd
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
JGJX
-
Fork Length:
-
1220mm
-
Fork Width:
-
140mm
-
Overall Dimensions:
-
3240*1500*2380mm
-
Weight (KG):
-
6000 kg
-
Model:
-
JG-T35A
-
Key words:
-
Hydraulic lift four wheel drive forklift
-
Product Type:
-
all rough terrain forklifts
-
Lifting height:
-
3m~ 6m
-
Engine:
-
Weichai490
-
Power:
-
40kw
-
Warranty::
-
1 Year
-
Loading Capacity:
-
3500kg
-
Transmission:
-
Electronic Hydraulic Transmisson
-
Drive mode:
-
4wd
High quality CE Euro5 EPA NEW Forklift with good price
Lifts 0.5ton to 12ton
Products Description
|
Parameter
|
|
|
|
|||
|
Model
|
T35A Low
|
Engine power
|
36.8kw
|
|||
|
Rated lifting load
|
3500kg
|
Drive type
|
4 wheel drive
|
|||
|
Rated lifting height
|
3000mm-6000mm
|
Gearbox
|
265 double high low speed torque converter
|
|||
|
Load center distance
|
600mm
|
Axle
|
Monoblock cast steel wheel reduction
|
|||
|
Min.turning radius
|
3200mm
|
Tire
|
12-16.5
|
|||
|
Gradeability
|
≤38°
|
Wheelbase
|
2200mm
|
|||
|
Min.ground clearance
|
300mm
|
Mast Steel Width
|
160mm
|
|||
|
Mast tilt angle (front/rear)
|
10°/6°
|
Fork length
|
1220mm
|
|||
|
Walking speed
|
38km/h
|
Overall weight
|
4200kg
|
|||
|
Max.traction
|
25KN
|
Dimensions
|
4100*1850*2200mm
|
|||
Features
1.
Mechanical joystick,
easy to operate.
2.
Thickened mast, strong bearing capacity.
3.
Hydraulic power steering wheel, easy to drive.
4.
LED light, h
igh brightness, energy saving.
5.
Engineering rubber tires, suitable for various road surfaces.
6.
Electrophoretic spray paint,
smooth and not easy to rust.
7.Cast steel axle,wheel reduction.
8.Both sides of the engine compartment can be opened for easy maintenance.
8.Both sides of the engine compartment can be opened for easy maintenance.
