Quick Details
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
SCG-52
-
Product Name:
-
Distribution Transformer
-
Rated current:
-
630A~1250A
-
Rated Voltage:
-
35KV/24KV/12KV/0.4KV
-
Shell protection grade:
-
Gas-Filled Shell IP67, Instrument room IP4X
-
Frequency:
-
50Hz/60Hz
-
Rated Short Circuit Breaking Current:
-
630A/630A
-
Cable Charging Breaking Current:
-
135A/135A
-
Rated capacity:
-
50,63,80,100,125,200,250,315,400,500,800,1000, 2000,2500A
-
Advantage:
-
Best price & Best quality in China
-
Product type:
-
Distribution Power Transformer Switch Cabinet Switchgear
-
Color:
-
Customizable
Quick Details
-
Voltage:
-
Low Voltage
-
Current:
-
630A~1250A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ABILKEEN
-
Model Number:
-
SCG-52
-
Product Name:
-
Distribution Transformer
-
Rated current:
-
630A~1250A
-
Rated Voltage:
-
35KV/24KV/12KV/0.4KV
-
Shell protection grade:
-
Gas-Filled Shell IP67, Instrument room IP4X
-
Frequency:
-
50Hz/60Hz
-
Rated Short Circuit Breaking Current:
-
630A/630A
-
Cable Charging Breaking Current:
-
135A/135A
-
Rated capacity:
-
50,63,80,100,125,200,250,315,400,500,800,1000, 2000,2500A
-
Advantage:
-
Best price & Best quality in China
-
Product type:
-
Distribution Power Transformer Switch Cabinet Switchgear
-
Color:
-
Customizable
Factory Workshop
Products Description
A1
1)ISO9001,IEC,Type Test Report
2)Top 3 in China and 23 Years' Manufacture
3)Sold to Malaysia,HK,Ethiopia, Mozambique, Kenya, Congo, Philippines,Nigeria,HK......and so on
2)Top 3 in China and 23 Years' Manufacture
3)Sold to Malaysia,HK,Ethiopia, Mozambique, Kenya, Congo, Philippines,Nigeria,HK......and so on
|
35KV high voltage switchgear technical parameter:
|
|
|
|
|
||||
|
Power Distribution System
|
|
|
Parameter
|
|
||||
|
Rated voltage
|
|
kV
|
40.5~33KV
|
|
||||
|
Rated short time power frequency withstand voltage(1min)(1min)
|
|
kV
|
95
|
|
||||
|
Rated lighting impulse withstand voltage
|
|
kV
|
185
|
|
||||
|
Rated frequency
|
|
Hz
|
50
|
|
||||
|
Rated current
|
|
A
|
6,301,250,160,020,000,000
|
|
||||
|
Rated short circuit breaking current
|
|
kA
|
25
|
31.5
|
||||
|
Rated peak value withstand current
|
|
kA
|
63
|
80
|
||||
|
Rated control power
|
|
V
|
AC 110/220,DC 110/220
|
|
||||
|
Dimension
|
KYN61-40.5
|
mm
|
1400*2800*2600
|
|
||||
|
|
|
|
(width* depth* height)
|
|
||||
|
24KV high voltage switchgear technical parameter:
|
|
|
|
|
||||
|
Power Distribution System
|
|
|
Parameter
|
|
||||
|
Rated voltage
|
|
kV
|
24~15KV
|
|
||||
|
Rated short time power frequency withstand voltage(1min)
|
|
kV
|
65
|
|
||||
|
Rated lighting impulse withstand voltage
|
|
kV
|
125
|
|
||||
|
Rated frequency
|
|
Hz
|
50
|
|
||||
|
Rated current
|
|
A
|
6,301,250,160,020,000,000
|
|
||||
|
Rated short circuit breaking current
|
|
kA
|
25
|
31.5
|
||||
|
Rated peak value withstand current
|
|
kA
|
63
|
80
|
||||
|
Rated control power
|
|
V
|
AC 110/220,DC 110/220
|
|
||||
|
Dimension
|
KYN28A-24
|
mm
|
1000*1800*2450(width*depth*heig
|
|
||||
|
12KV high voltage switchgear technical parameter:
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
Parameter
|
|
|
|
|
|||||||
|
Rated voltage
|
|
kV
|
3.6
|
|
7.2
|
|
12
|
|||||||
|
Rated short time power frequency withstand voltage(1min)
|
|
kV
|
24
|
|
32
|
|
42
|
|||||||
|
Rated lighting impulse withstand voltage
|
|
kV
|
40
|
|
60
|
|
75
|
|||||||
|
Rated frequency
|
|
Hz
|
50
|
|
|
|
|
|||||||
|
Rated current
|
|
A
|
630,1250,1600,2000,2500,3150,4000
|
|
|
|
|
|||||||
|
Rated short circuit breaking current
|
|
kA
|
20
|
25
|
31.5
|
40
|
50
|
|||||||
|
Rated peak value withstand current
|
|
kA
|
50
|
63
|
80
|
100
|
125
|
|||||||
|
Rated control power
|
|
V
|
AC 110/220,DC 110/220
|
|
|
|
|
|||||||
|
Dimension (width*depth*height)
|
KYN28A-12
|
mm
|
(800/1000)*1500*2300
|
|
|
|
|
|||||||
|
(width*depth*height)
|
XGN2-12
|
mm
|
1100*1200*2650
|
|
|
|
|
|||||||
|
|
HXGN-12
|
mm
|
(375/500)*900*1850
|
|
|
|
|
|||||||
|
0.4KV low voltage switchgear technical parameter:
|
|
|
|
|
||||
|
|
|
|
Parameter
|
|
||||
|
Rated voltage
|
|
V
|
400
|
690
|
||||
|
Rated insulation voltage
|
|
V
|
690
|
1140
|
||||
|
Rated impact withstand voltage
|
|
V
|
6000
|
10000
|
||||
|
Rated working short circuit breaking ability
|
|
kA
|
18~100
|
10~75
|
||||
|
Rated utmost short circuit breaking ability
|
|
kA
|
25~120
|
20~85
|
||||
|
Rated frequency
|
|
Hz
|
50/60
|
|
||||
|
Rated current
|
|
A
|
400,500,630,800,1000,1250,1600,2000,2500,3150,4000,5000,6300
|
|
||||
|
Rated control power
|
|
V
|
AC 110/220/380,DC 110/220
|
|
||||
|
Dimension
|
MNS/GCS/GGD
|
width
|
40,060,080,010,001,200
|
|
||||
|
(Unit:mm)
|
|
depth
|
6,008,001,000
|
|
||||
|
|
|
height
|
2200
|
|
||||
Feature:
1.PreveNT THE GAS let out and moisture absorption, design for safety.(Protection level IP67)
2.Use five-protection mechanical interlock and electric interlock conformed to power grid system requirement and Effectively avoid faulty operation
3.Use force and thermal analysls to realize maintenance free thus save operation costs
4.Each independent functional unit is equipped with a pressure relief channel to effectively prevent the expansion of accidents
5.mechanical life:30000 Times (SIEIVIENS 3AHX) Electrical life:10000 Times (SIEIVIENS 3AHX)
