- Product Details
- {{item.text}}
Quick Details
-
Dimension (L*W*H):
-
440*300*158mm
-
Weight:
-
65Kg
-
Battery Style:
-
wall mounted battery
-
Warranty:
-
10 Years
-
Inverters compatible:
-
Solax / Deye / Growatt / Victron / Goodwe / Sofar Solar etc.
-
Applicationt 1:
-
Household energy storage
-
Applicationt 2:
-
Commercial energy storage
-
Applicationt 3:
-
Electric power systems
-
Certification:
-
CE / ROSH / VDE / MSDS / UN38.3 / IEC
-
Cycle life:
-
6000
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
Quick Details
-
Model Number:
-
SP-24100-BG-WC
-
Brand Name:
-
SUNPOK ENERGY
-
Place of Origin:
-
Guangdong, China
-
Dimension (L*W*H):
-
440*300*158mm
-
Weight:
-
65Kg
-
Battery Style:
-
wall mounted battery
-
Warranty:
-
10 Years
-
Inverters compatible:
-
Solax / Deye / Growatt / Victron / Goodwe / Sofar Solar etc.
-
Applicationt 1:
-
Household energy storage
-
Applicationt 2:
-
Commercial energy storage
-
Applicationt 3:
-
Electric power systems
-
Certification:
-
CE / ROSH / VDE / MSDS / UN38.3 / IEC
-
Cycle life:
-
6000
-
OEM/ODM:
-
Customized OEM ODM Battery Pack
Products Description
|
BATTERY SPECIFICATIONS
|
|
|
||
|
Model No
|
SP-24200-BG-WC
|
SP48100-BG-WC
|
||
|
Voltage
|
25.6V
|
51.2V
|
||
|
Capacity
|
100Ah/120Ah/200Ah
|
100Ah/120Ah/200Ah
|
||
|
Operation voltage
|
44-58.4Vdc
|
44-58.4Vdc
|
||
|
Max.charging voltage
|
58.4Vdc
|
58.4Vdc
|
||
|
Max.charging and discharging current
|
50A
|
100A
|
||
|
Max Power
|
5120W
|
5120W
|
||
|
Life time(25°C)
|
20 Years
|
|
||
|
Life cycles(80% DOD, 25°C)
|
6000 Cycles
|
|
||
|
Storage time / temperature
|
5 months @ 25°C; 3 months @ 35°C; 1 month @ 45°C
|
|
||
|
Operation temperature
|
-20°C to 60°C @60+/-25% Relative Humidity
|
|
||
|
Storage temperature
|
0°C to 45°C @60+/-25% Relative Humidity
|
|
||
|
Lithium Battery Standard
|
UL1642, IEC62619, UN38.3, MSDS,ROHS,CE-EMC
|
|
||
|
Enclosure protection rating
|
IP21
|
|
||
|
Dimensions(L×W×H)
|
500*440*240mm
|
|
||
|
Weight
|
19.3Kg
|
65Kg
|
||
Sunpok energy storage batteries are compatible all off-grid/hybrid inverters.
If you want to get a whole solar energy storage system solution, please contact the customer manager of Sunpok, or directly click the picture above to transfer to the sales page of the solar energy system.
