Quick Details
-
Color:
-
16bits Full color
-
Panel Size:
-
960*240mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-TAD
-
Brightness:
-
1500-5000nits
-
pixel density:
-
15625dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
16bits
-
Lifespan (hours):
-
100000hours
-
IP Rating:
-
IP45
-
Resolution:
-
120*30dot/cabinet
-
View Angle（H/V）:
-
160/160
-
Refresh Rate(Hz):
-
≥3840
-
LED Light:
-
2020 RGB
-
Grey Scale(Bit):
-
16
-
Screen weight:
-
≤2kg/m2
-
Installation Mode:
-
Fixed installation
-
Screen Transparency:
-
>50%-95%
-
Material:
-
Aluminum
-
Control system:
-
Novastar System
-
Installation method:
-
Adhering to glass, hanging installation, fixed installation,
Quick Details
-
Application:
-
Indoor
-
Type:
-
LED
-
Brand Name:
-
DDW
-
Color:
-
16bits Full color
-
Panel Size:
-
960*240mm
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DDW-TAD
-
Brightness:
-
1500-5000nits
-
pixel density:
-
15625dots/m2
-
Contrast Ratio:
-
5000:1
-
Color Depth:
-
16bits
-
Lifespan (hours):
-
100000hours
-
IP Rating:
-
IP45
-
Resolution:
-
120*30dot/cabinet
-
View Angle（H/V）:
-
160/160
-
Refresh Rate(Hz):
-
≥3840
-
LED Light:
-
2020 RGB
-
Grey Scale(Bit):
-
16
-
Screen weight:
-
≤2kg/m2
-
Installation Mode:
-
Fixed installation
-
Screen Transparency:
-
>50%-95%
-
Material:
-
Aluminum
-
Control system:
-
Novastar System
-
Installation method:
-
Adhering to glass, hanging installation, fixed installation,
Discover Your Right Application , Make Your Business Possible !
Common warranty in LED field is 2 years, ours is 3 years Longer warranty
periods, better after-sale services, worry-free user experience
Products Description
Specifications
|
Pixel Pitch
|
P2/P3/P4/P5/P6/P8/P10/P16/P20/P31.25/P40/P50/P60
|
|
Display Thickness
|
1-3mm
|
|
LED chip
|
SMD2020
|
|
Product Size
|
960*160mm/960*256mm
960*320mm/1000*160mm 1200*320mm/1200*480mm |
|
Power consumption
|
Average：240W/㎡，Maximum：800W/㎡
|
|
Screen Weight
|
≤2kg/m²
|
|
Power Supply Brand
|
YUANCHI
|
|
Screen Transparency
|
＞50%-95%
|
|
IP Rating
|
IP45
|
|
Average Lifespan
|
≥100,000 operating hours
|
|
Power Requirements
|
110-220V±10%; AC50/60HZ
|
|
Screen Brightness
|
1500-5000cd/m²
|
|
Viewing Distance
|
6m-250m
|
|
Viewing Angle
|
Horizontal ≥160°, Vertical ≥140°
|
|
Gray Level
|
≥16bit
|
|
Color Temperature
|
5500K-15000K (adjustable)
|
|
Driving Method
|
Static
|
|
Attenuation Rate
|
Less than 0.05% in 2 years
|
|
Refresh Rate
|
≥3840Hz
|
|
Frame Rate
|
≥60Hz
|
|
Trouble-Free Operating Time
|
≥10,000 hours
|
|
. L ed chip Failure Rate
|
≤1/10,000
|
|
Control System
|
Colorlight/Novastar
|
|
Operating Environment
|
-10~+65 ℃
|
|
Installation Method
|
Adhering to glass, Hanging installation, fixed installation. Support arbitrary size cropping and bending
|
