Automatic ticketing System
Financial to public savings system
Railway real-time station reporting system
And other serial device control systems
- Product Details
- {{item.text}}
Quick Details
-
Product name:
-
pci serial Card
-
chipset:
-
WCH351
-
Application:
-
laptop
-
Package:
-
PE Bag +Carton Box
-
Compliant:
-
PCI Express Base Specification 1.0a
-
os:
-
W98/Me/NT4.0/2000 /XP/Vista /7 / Server 2003 / Serv
-
Color:
-
Black
-
Material:
-
Plastic+Metal
-
Lead time:
-
3-7 days
-
keyword:
-
PCI RS232 card
Quick Details
-
Products Status:
-
Stock, Used
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Product name:
-
pci serial Card
-
chipset:
-
WCH351
-
Application:
-
laptop
-
Package:
-
PE Bag +Carton Box
-
Compliant:
-
PCI Express Base Specification 1.0a
-
os:
-
W98/Me/NT4.0/2000 /XP/Vista /7 / Server 2003 / Serv
-
Color:
-
Black
-
Material:
-
Plastic+Metal
-
Lead time:
-
3-7 days
-
keyword:
-
PCI RS232 card
Product Description
RS-232 DB9 S
erial
2-port pci express
extension
card
|
About The Product:
Plug and play, automatic allocation of IRQ and I/O address, no switch and no jumpers, easy setting using software, 32-bit bus design, support PCI 2.1 specification, using high-speed I/O controller (16C550C or compatible UART) a machine can be connected to multiple serial ports
|
|
Specifications: PCI
1. Comply with PCI2.1 specification and support 32-bit PCI bus.
2. Plug and play, automatically assign IRQ and I/O addresses. 3. A host can support multiple serial port cards. 4. Data bit length: 4, 5, 6, 7, 8 bit bytes. 5. Check method: NONE EVEN OLD SPACE MARK. 6. Stop bit length: 1,1.5, 2. 7. data flow control mode: None, hardware, Xon/Xoff. 8. Support WINDOWS 2000/2003/XP operating system. 9. The maximum data transmission rate can reach 1M/S. 10. Meet the RoHS standard. |
Main Functions of products
PCI
Serial
expansion card
Automatic ticketing System
Financial to public savings system
Railway real-time station reporting system
And other serial device control systems
Product installation
The IO-PCI60806A 2S driver is on the disc.
Install Windows 2000 /XP drivers
1. Start the Windows operating system.
2. Windows automatically detects the PCI TO R232 expansion card. Click the "Next" button to continue.
3. Select Install from List or Specify (recommended) and click the Next button.
4. Insert the driver CD-ROM into the CDROM. Select "Include this location in Search (O) :" and click the "Browse" button to continue the installation.
5. Browse in the WINDOWS folder:
a. Select the CDROM drive. b. Double-click the SIE folder. c. Double-click folder 60806A. d. Click OK. e. Click the Next button.
6. The Windows system will automatically locate the file in the driver CD-ROM. Click the Next button to continue.
7. Click Finish to start copying files from the driver CD-ROM.
8. The Windows system automatically refreshes the hardware configuration.
9. The Windows system is restarted and the PCI TO RS232 expansion card can be used.
10. After the program is run, the system will automatically restart to complete the driver installation.
Install Windows 2000 /XP drivers
1. Start the Windows operating system.
2. Windows automatically detects the PCI TO R232 expansion card. Click the "Next" button to continue.
3. Select Install from List or Specify (recommended) and click the Next button.
4. Insert the driver CD-ROM into the CDROM. Select "Include this location in Search (O) :" and click the "Browse" button to continue the installation.
5. Browse in the WINDOWS folder:
a. Select the CDROM drive. b. Double-click the SIE folder. c. Double-click folder 60806A. d. Click OK. e. Click the Next button.
6. The Windows system will automatically locate the file in the driver CD-ROM. Click the Next button to continue.
7. Click Finish to start copying files from the driver CD-ROM.
8. The Windows system automatically refreshes the hardware configuration.
9. The Windows system is restarted and the PCI TO RS232 expansion card can be used.
10. After the program is run, the system will automatically restart to complete the driver installation.
Details Images
PCI gold plated finger
Thick gold plating process, good electrical conductivity, oxidation resistance, good contact, more stable operation
9pin dual serial port
1 Carrier detection (DCD) 2 Received data (RXD) 3 Sent data (TXD) 4 Data Terminal ready (DTR) 5 Signal ground (GND) 6 Data ready (DSR) 7 Sent Request (RTS) 8 Sent Clear (CTS) 9 Ringing indication
High-speed transmission
The chip is stable and compatible with Windows 2000/2003/XP operating system. , data transmission speed up to 1M/S
Product Usage
Applicable PCI ports
No-PCI ports are unavailable
Install a serial port expansion card in the PCI card slot on the computer motherboard, and add two serial ports at the back of the computer
Packing&Shipping
Sample & small quantity order is welcomed.
OEM service is available. If you have your own ideas, we can help you complete, such as: color and pattern. Customize the
LOGO.Custom packaging. * Single product packaging 148*130*30mm, weight 81g 100 pieces are packed into a box, the size of the box is 69*29*31cm , and the weight is 10kg
LOGO.Custom packaging. * Single product packaging 148*130*30mm, weight 81g 100 pieces are packed into a box, the size of the box is 69*29*31cm , and the weight is 10kg
