Quick Details
-
Brand Name:
-
Greensky Power
-
Model Number:
-
6I(R)K120GU
-
Frequency:
-
50Hz / 60Hz
-
Gear ratio:
-
3-500
-
Size:
-
100mm*100mm
-
Customized:
-
Yes
-
Accessaries:
-
brake, speed controller, thermal protector, terminal box
-
Service:
-
OEM
-
Certification:
-
CE
Quick Details
-
AC Voltage:
-
1ph 110/220V; 3ph 220/380V
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Greensky Power
-
Model Number:
-
6I(R)K120GU
-
Frequency:
-
50Hz / 60Hz
-
Gear ratio:
-
3-500
-
Size:
-
100mm*100mm
-
Customized:
-
Yes
-
Accessaries:
-
brake, speed controller, thermal protector, terminal box
-
Service:
-
OEM
-
Certification:
-
CE
1. Light weight, compact dimension ;
2. Wide speed range and high torque;
3. Low noise and high efficiency;
4. Stable and safe,long lifetime;
5. Multi-structure, various assembling methods;
6. One-stop solution with speed controller, driver, encoder, brake and transformor available.
Motor Characteristics
| Motor Model | Specs | Output power | Voltage | Frequency | Current | Starting Torque | Rated Torque | Rated Speed | Capacitor/Ve |
| W | V | Hz | A | mN.m | mN.m | r/min | μF/VAC | ||
|
GS6IK120GU-CF
GS6IK120A-CF |
Induction | 120 |
1-phase
220 |
50 | 1 | 1100 | 880 | 1350 | 6/450 |
| 60 | 1 | 925 | 740 | 1550 | 6/450 | ||||
|
GS6RK120GU-CF
GS6RK120A-CF |
Reversible
30min |
50 | 1.2 | 1575 | 1260 | 1350 | 8/450 | ||
| 60 | 1.4 | 1225 | 980 | 1550 | 8/450 | ||||
|
GS6IK120GU-AF
GS6IK120A-AF |
Induction | 120 |
1-phase
110 |
50 | 1.7 | 1100 | 880 | 1350 | 30/250 |
| 60 | 1.6 | 925 | 740 | 1550 | 28/250 | ||||
|
GS6RK120GU-AF
GS6RK120A-AF |
Reversible
30min |
50 | 1.8 | 1575 | 1260 | 1350 | 32/250 | ||
| 60 | 2.0 | 1225 | 980 | 1550 | 32/250 | ||||
|
GS6IK120GU-UF
GS6IK120A-UF |
—— | 120 |
3-phase
380 |
50 | 0.46 | 1100 | 880 | 1350 | —— |
| 60 | 0.42 | 925 | 740 | 1550 | —— | ||||
|
GS6IK120GU-SF
GS6IK120A-SF |
—— | 120 |
3-phase
220 |
50 | 0.8 | 1100 | 880 | 1350 | —— |
| 60 | 0.73 | 925 | 740 | 1550 | —— |
Allowable load for the gear motor
|
Geared-down
parameter |
Synchronous speed
r/min |
500 | 300 | 200 | 150 | 120 | 100 | 83 | 75 | 60 | 50 | 41 | 37 | 30 | 25 | 20 | 15 | 12 | 10 | 8 | 7 | 6 | 5 | 3 | |
| Ratio i | 3 | 5 | 7.5 | 10 | 12.5 | 15 | 18 | 20 | 25 | 30 | 36 | 40 | 50 | 60 | 75 | 100 | 120 | 150 | 180 | 200 | 250 | 300 | 500 | ||
| Max allowable load | 120W | N.m | 2.11 | 3.52 | 5.28 | 6.85 | 8.45 | 10.2 | 12.3 | 13.6 | 16.9 | 20.5 | 22.14 | 24.6 | 31 | ||||||||||
Dimensional Drawing
