- Product Details
- {{item.text}}
Quick Details
-
Application:
-
0.8-2 ton
-
Supply Ability:
-
1000 Piece/Pieces per Month
-
After Warranty Service:
-
Video technical support
-
Packing:
-
Customized Packing
-
Color:
-
Customised
-
Delivery time:
-
Within 7-15 Working Days
-
Feature:
-
High Qulity
Quick Details
-
Place of Origin:
-
Shandong, China, Shandong, China
-
Brand Name:
-
Weitai
-
Model Number:
-
PHV-1B-12B
-
Application:
-
0.8-2 ton
-
Supply Ability:
-
1000 Piece/Pieces per Month
-
After Warranty Service:
-
Video technical support
-
Packing:
-
Customized Packing
-
Color:
-
Customised
-
Delivery time:
-
Within 7-15 Working Days
-
Feature:
-
High Qulity
|
Model
|
Max Working Pressure
|
Max. Output Torque
|
Max. Output Speed
|
Speed
|
Oil Port
|
Application
|
|
PHV-1B-12B
|
21 MPa
|
1500 N.m
|
82 rpm
|
2-speed
|
4 ports
|
0.8-2 Ton Excavators
|
|
Frame flange orientation diameter
|
140 mm
|
|
Frame flange bolt pattern
|
8-M10 Equally
|
|
Frame flange holes P.C.D.
|
155 mm
|
|
Sprocket flange orientation diameter
|
140 mm
|
|
Sprocket flange bolt pattern
|
9-M10 Equally
|
|
Sprocket flange holes P.C.D.
|
155 mm
|
|
Flange distance
|
45 mm
|
|
Approximate weight
|
20 kg (44 lbs)
|
Production Process
Recommended Products
COMPANY PROFILE
Why Choose WEITAI
Certifications
FAQ
1) What types of hydraulic motors does your company produce?
A: WEITAI mainly produces complete and fully assembled brand new axial piston motors integrated with planetary gearboxes, which are widely used for track equipment. We can also produce hydraulic motors for wheeled machines.
2) Hydraulic motors of which brands can be replaced with WEITAI's ones?
A: Our motors are interchangeable with the motors of the following brands: Eaton, Doosan, Jeil, KYB, Nachi, Nabtesco, Rexroth, Poclain, Bonfiglioli, etc.
3) How can I choose the right model of the hydraulic motor to fit my machine?
A: Different markets have different machine variations. The best way to find the right motor is to look at the motor brand and the machine model you have. Another way would be by measuring the key dimensions of the flange frame and the sprocket flange. Please contact our sales team to get technical support if you have difficulties choosing the right motor for your application.
4) Can you produce hydraulic motors based on your customer's designs and dimensions?
A: Yes, we can. We are ready to provide the best customized hydraulic solutions for your business.
5) Can the OEM parts apply to WEITAI's travel motors?
A: No, they cannot. Although they might have a similar appearance, their internal structures are different. Only WEITAI's spare parts can fit WEITAI's travel motors.
6) What information do we need our customers to provide while choosing the right hydraulic motor for their application?
A: (1) Drawing, or (2) original motor model, or (3) machine model and part No.
A: WEITAI mainly produces complete and fully assembled brand new axial piston motors integrated with planetary gearboxes, which are widely used for track equipment. We can also produce hydraulic motors for wheeled machines.
2) Hydraulic motors of which brands can be replaced with WEITAI's ones?
A: Our motors are interchangeable with the motors of the following brands: Eaton, Doosan, Jeil, KYB, Nachi, Nabtesco, Rexroth, Poclain, Bonfiglioli, etc.
3) How can I choose the right model of the hydraulic motor to fit my machine?
A: Different markets have different machine variations. The best way to find the right motor is to look at the motor brand and the machine model you have. Another way would be by measuring the key dimensions of the flange frame and the sprocket flange. Please contact our sales team to get technical support if you have difficulties choosing the right motor for your application.
4) Can you produce hydraulic motors based on your customer's designs and dimensions?
A: Yes, we can. We are ready to provide the best customized hydraulic solutions for your business.
5) Can the OEM parts apply to WEITAI's travel motors?
A: No, they cannot. Although they might have a similar appearance, their internal structures are different. Only WEITAI's spare parts can fit WEITAI's travel motors.
6) What information do we need our customers to provide while choosing the right hydraulic motor for their application?
A: (1) Drawing, or (2) original motor model, or (3) machine model and part No.
