Quick Details
-
Application:
-
FAN, General Purpose
-
Color:
-
Black
-
Material:
-
Metalized Polypropylene
-
Capacitance tolerance:
-
5%(J)
-
Terminal:
-
Lead Wire
-
Package / Case:
-
Normal Package
-
Certificate:
-
RoHS/CE/ISO9000
-
Capacitance:
-
8UF
-
Rated Voltage:
-
450V
-
Operating Temperature:
-
40/70/21
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
odoelec
-
Model Number:
-
cbb61 8uf 450v
-
Application:
-
FAN, General Purpose
-
Color:
-
Black
-
Material:
-
Metalized Polypropylene
-
Capacitance tolerance:
-
5%(J)
-
Terminal:
-
Lead Wire
-
Package / Case:
-
Normal Package
-
Certificate:
-
RoHS/CE/ISO9000
-
Capacitance:
-
8UF
-
Rated Voltage:
-
450V
-
Operating Temperature:
-
40/70/21
CBB61 8uf 450V Fan Motor 50/60hz Electric Capacitor
1.Product Characteristics
With a small loss, anti-moist, excellent electrical performance, reliability, large capacity, long life and good self-healing properties.
2.Product Applications:
This product is suitable for equipment, the instrument so on electric fan, washing machine, electric refrigerator, air conditioning alternating current machine start and the revolution.
3.General specifications:
|
Item |
Technical Specification |
|
Operating Temperature |
-40 °C-+70°C |
|
Capacitance Range |
0.8uf-25uf |
|
Capacitance Tolerance |
J (±5%), K(±10%) |
|
Rated Voltage |
250V, 400V, 450V, 630V |
|
Withstand Voltage |
AC ≥1.75Un 2S (Imax≤1.3InA) |
|
Dissipation Factor |
≤0.004 (20°C,1kHz) ≤0.002(20°C,100Hz) |
|
Insulation Resistance |
≥3000S |
|
Weather Category |
40/70/21 |
4.Standard dimensions:
|
Capacitance Range (uf) |
Rated Voltage |
||
|
250V |
400V-450V L*W*H |
630V |
|
|
1 |
36.5 ×11×24.5 |
36.5 ×11×24.5 |
36.5 ×16×29.5 |
|
1.5 |
36.5 ×11×24.5 |
36.5 ×11×24.5 |
36.5 ×16×29.5 |
|
2 |
36.5 ×11×24.5 |
36.5 ×16×29.5 |
38 ×20×30 |
|
2.4 |
36.5 ×11×24.5 |
36.5 ×16×29.5 |
47 ×17.5×34.5 |
|
3 |
36.5 ×16×29.5 |
38 ×20×30 |
47 ×17.5×34.5 |
|
3.5 |
36.5 ×16×29.5 |
38 ×20×30 |
47 ×20×37.5 |
|
4 |
38 ×20×30 |
47 ×17.5×34.5 |
47 ×20×37.5 |
|
5 |
47 ×17.5×34.5 |
47 ×20×37.5 |
50 ×23×40 |
|
6 |
47 ×17.5×34.5 |
47 ×20×37.5 |
50 ×23×40 |
|
8 |
47 ×20×37.5 |
50 ×23×40 |
58 ×25×42 |
|
10 |
47 ×20×37.5 |
58 ×25×42 |
58 ×25×42 |
|
12 |
47 ×20×37.5 |
58 ×25×42 |
58 ×31×57 |
|
15 |
50 ×23×40 |
58 ×28×50 |
58 ×31×57 |
|
20 |
58 ×25×42 |
58 ×31×57 |
|
|
25 |
58 ×25×42 |
|
|
