Quick Details
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Jiufu
-
Product name:
-
Dutch Woven Wire Mesh
-
Usage:
-
Filter
-
Length:
-
30m/roll
-
MOQ:
-
30 Square Meter
-
Color:
-
Stainless Steel Color
Quick Details
-
Material:
-
STAINLESS STEEL WIRE
-
Type:
-
Weave Wire Mesh
-
Application:
-
Woven Wire Mesh
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Jiufu
-
Product name:
-
Dutch Woven Wire Mesh
-
Usage:
-
Filter
-
Length:
-
30m/roll
-
MOQ:
-
30 Square Meter
-
Color:
-
Stainless Steel Color
Stainless Steel Dutch Weave Wire Fabric Mesh/Reverse Dutch Weave Wire Mesh Belt
Product Description
1.Material:
AISI302, 304,316,316L,310S,410,430,904L,2205,2507,etc
2 . Wire Diameter: 0.015-2.8mm
3 . Mesh Count:
Plain weave can be woven up to 400 mesh.
Twill weave can be woven from 400 to 635mesh.
Dutch weave can be woven up to 3500mesh
2 . Wire Diameter: 0.015-2.8mm
3 . Mesh Count:
Plain weave can be woven up to 400 mesh.
Twill weave can be woven from 400 to 635mesh.
Dutch weave can be woven up to 3500mesh
4. What is Mesh Count?
5.Weave Pattern
: Plain Weave ,Twill Weave,Dutch Weave,etc.
6.
Dutch Weave Wire Cloth
has four types of weaves, which has plain dutch woven,twill dutch woven, reverse dutch woven and five
heddle weave.
Dutch woven wire filter cloth can be weaved by stainless steel wire, nickel wire, brass wire and galvanized wire.
Dutch woven wire filter cloth can be weaved by stainless steel wire, nickel wire, brass wire and galvanized wire.
Specification
Stainless Steel Plain Dutch Weave Wire Cloth
Plain Dutch Woven Wire Cloth
is woven with a large wire diameter in the warp direction and a relatively smaller wire in the shute
direction. This weave has great strength and is available in wide range of micron ranges. It is primarity used to filter a wide
range of liquid and slurry products.
direction. This weave has great strength and is available in wide range of micron ranges. It is primarity used to filter a wide
range of liquid and slurry products.
Stainless Steel Twill Dutch Weave Wire Cloth
Twill Dutch Weave Wire Cloth
is the larger diameter warp wires successively pass over and under the lighter diameter shute wires.
Each pass of the shute wires shifts the over and under movement one wire. The shute wires are driven up close, resulting in a
tightly woven filter cloth with tapered or wedge shaped openings.
Each pass of the shute wires shifts the over and under movement one wire. The shute wires are driven up close, resulting in a
tightly woven filter cloth with tapered or wedge shaped openings.
Reverse Dutch Weave Wire Cloth
Reverse Dutch Weave Wire Cloth
is a very strong woven product.This mesh is ideal for making filter belts, and applications where
fine filtration and great strength are required.
Properties: Very good flow rates, small pressure drop; surface is slightly structured.
Applications: Pressure and vacuum filters; filter candles.
fine filtration and great strength are required.
Properties: Very good flow rates, small pressure drop; surface is slightly structured.
Applications: Pressure and vacuum filters; filter candles.
Details Images
Plain Dutch Woven Wire Cloth
Reverse Dutch Weave Wire Cloth
Mesh Filter Elements
Exhibition
Packing & Delivery
Plastic Film + Water-proof Paper + Woven Bag + Wooden Box or Pallet
