- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Choke System:
-
Automatic
-
Transmission:
-
CVT
-
Front & Rear tyre size:
-
25x8-12 / 25x10-12
-
Certification:
-
EPA ,EEC5, CE
-
Horse Power:
-
18KW ( 6500rpm) 25HP
-
Suspension Front:
-
Double A-arm Suspension
-
Suspension Rear:
-
4 Link Bar Rear Suspension
-
Max speed:
-
75km/h
Quick Details
-
Displacement:
-
>300cc
-
Brand Name:
-
shengwo
-
Tire Size:
-
25x8-12 / 25x10-12
-
Place of Origin:
-
Shandong, China
-
Choke System:
-
Automatic
-
Transmission:
-
CVT
-
Front & Rear tyre size:
-
25x8-12 / 25x10-12
-
Certification:
-
EPA ,EEC5, CE
-
Horse Power:
-
18KW ( 6500rpm) 25HP
-
Suspension Front:
-
Double A-arm Suspension
-
Suspension Rear:
-
4 Link Bar Rear Suspension
-
Max speed:
-
75km/h
Product Description
|
ENGINE
|
|
SUSPENSION / BRAKES
|
|
||
|
Engine style
|
4-stroke,Single-Cylinder, Water-cooled
|
Suspension Front
|
Double A-arm Suspension
|
||
|
Horse Power
|
18KW ( 6500rpm) 25HP
|
Suspension Rear
|
Fang power 4-Link® bar Rear Suspension
|
||
|
Valve Configuration
|
OHV
|
Brakes Front
|
220MM Front Dual Hydraulic Disk
|
||
|
Compression ratio
|
10.0:1
|
Brakes Rear
|
220MM Rear Dual Hydraulic Disk
|
||
|
FUEL SYSTEM
|
|
TIRES
|
|
||
|
Fuel Delivery System
|
E5 DELPHI EFI ENGINE
|
Front Tread
|
1250mm ( 49.2 in)
|
||
|
Choke System
|
Automatic
|
Rear Tread
|
1150mm ( 45.2in)
|
||
|
Fuel capacity
|
9.5L (2.1 Gallon)
|
Front & Rear tire size
|
25x8-12 / 25x10-12
|
||
|
DRIVETRAIN
|
|
MISC
|
|
||
|
Driveline Type
|
4X2
|
Loading information
|
8units/20″;; 24units/40HQ
|
||
|
Transmission
|
Constantly Variable Transmission
|
Manufacturers Warranty
|
6 Months
|
||
|
Gear Selection
|
Forward & Reverse Single Speed
|
Top speed
|
75km/h
|
||
|
ELECTRICAL SYSTEM
|
|
Dry weight
|
400KGS
|
||
|
Forward Lights
|
Headlights-High & Low Beam
|
Gross weight
|
470kgs
|
||
|
Rear Lights
|
Brake Lights & Left/Right Signal lights
|
Wheelbase
|
1980mm
|
||
|
Starting system
|
Electric start
|
Vehicle dimension(L×W×H)
|
2700x1450x1750mm
|
||
|
Ignition system
|
D.C.D.I
|
Packing size
|
2290x1400x815mm
|
||
|
|
|
Ground clearance
|
300mm(11.8in)
|
||
|
|
|
Safety
|
Driver & Passenger Seat belts/ Driver and Passenger safety net restraints.
|
||
