Quick Details
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12500kg
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Online support, Free spare parts
-
Place of Origin:
-
SHN
-
Dimensions (L x W x H) (mm):
-
6980*2496*3150mm
-
Cargo Tank Dimension:
-
5800*2300*1500mm
-
Wheelbase:
-
3775+1400mm
-
GVW (T):
-
≤50t
-
Max Speed(km/h):
-
45~65/110
-
Engine Model:
-
WP10.336E53
-
MaxTorque/Speed:
-
1200-1500rpm
-
Fuel Tanker Capacity(L):
-
300L Aluminum alloy
-
Tire:
-
12.00R20
-
Qty Of Tire:
-
10+1
-
Battery:
-
maintenance-free battery
Quick Details
-
Condition:
-
New
-
Horsepower:
-
251 - 350hp
-
Emission Standard:
-
Euro 2
-
Market Segement:
-
Mining transportation
-
Engine Capacity:
-
> 8L
-
Gross Vehicle Weight:
-
12500kg
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Online support, Free spare parts
-
Place of Origin:
-
SHN
-
Dimensions (L x W x H) (mm):
-
6980*2496*3150mm
-
Cargo Tank Dimension:
-
5800*2300*1500mm
-
Wheelbase:
-
3775+1400mm
-
GVW (T):
-
≤50t
-
Max Speed(km/h):
-
45~65/110
-
Engine Model:
-
WP10.336E53
-
MaxTorque/Speed:
-
1200-1500rpm
-
Fuel Tanker Capacity(L):
-
300L Aluminum alloy
-
Tire:
-
12.00R20
-
Qty Of Tire:
-
10+1
-
Battery:
-
maintenance-free battery
M achine structure
Machine parameter
|
SX3258MR384 |
|||
|
Wheelbase |
3775+1400 mm |
||
|
GVW (T) |
≤50t |
||
|
Max Speed( km/h) |
45~ 65/110 |
||
|
Containner Size Thickness ( mm ) & Related parameters
|
5 8 00 * 2300 * 1500mm China Brand Front Lift Φ 180 oil cylinder |
||
|
Engine( WEICHAI) |
Model |
WP10.336E53 |
|
|
|
Fuel Type |
||
|
Emission |
Eur3 |
||
|
Rate Power(kw/HP) |
247kW/336HP |
||
|
MaxTorque /Speed |
1200-1500rpm |
||
|
Displace (L) |
9.726L |
||
|
Fuel Tanker Capacity( L ) |
|||
|
Clutch |
Model |
φ430 |
|
|
Transmission |
Model |
10JSD180+QH50 |
|
|
Cross |
Section Dimension Frame( mm ) |
850×300(8+7) |
|
|
|
|||
|
Front Axle |
MAN 9 .5T |
||
|
|
|||
|
Rear Axle |
16T MAN 5.262 |
||
|
|
|||
|
Tire |
12.00R20
|
||
|
Qty Of Tire |
|||
|
Battery |
maintenance-free battery |
||
|
Cab & Basic configuration
|
H3000 cab,Hydraulic main seat, four-point hydraulic suspension cab, pole rearview mirror, electric air conditioning, electric shaking window machine, manual rotation, telescopic shaft operation, ordinary air filter, metal bumper, two-stage pedal, water tank protection grid, 165Ah maintenance-free battery (Cummins model standard with 180Ah maintenance-free battery), SHACMAN logo, English logo |
||
Machine features
1.More than 10years food and agricultural machine produce experience
2. Excellent sales team to provide professional advice to customers in different countries
3. Professional technical team and production workshop to ensure quality
4. Efficient logistics service and after-sales team to ensure the satisfaction of the purchase
