Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Kerise
-
Working Width:
-
1350-1750mm
-
Power:
-
20-55hp
-
Blade:
-
32PCS
-
Input Power:
-
540RPM
-
Measurement:
-
2020*920*960mm
Quick Details
-
Weight (KG):
-
450
-
Type:
-
lawn mower
-
Use:
-
mowing
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Kerise
-
Working Width:
-
1350-1750mm
-
Power:
-
20-55hp
-
Blade:
-
32PCS
-
Input Power:
-
540RPM
-
Measurement:
-
2020*920*960mm
Specification
|
Technical Data
|
BCRM-135
|
BCRM-155
|
BCRM-175
|
||
|
Dimensions (LxWxH)
|
1680x1500x610mm / 67x59x24inch
|
1680x1700x610mm / 67x67x24inch
|
1680x1900x610mm / 67x75x24inch
|
||
|
Total Weight
|
414KG / 912lbs
|
431KG / 950lbs
|
447KG / 985lbs
|
||
|
Cutting Width
|
1350mm / 53inch
|
1550mm / 61inch
|
1750mm / 68inch
|
||
|
Adjustable Mowing Height
|
20 - 75mm / 0.75 - 2.95inch
|
|
|
||
|
Hydraulic Side Movement
|
1105mm / 43inch
|
|
|
||
|
Max. Range From Middle Of Tractor
|
2005mm / 78inch (Horizontal Position)
|
2205mm / 86inch (horizontal position)
|
2405mm / 94inch (Horizontal Position)
|
||
|
Max. Range From Middle Of Tractor
|
1343mm / 52inch(In 90° Pposition For HedgeTrimming)
|
|
|
||
|
Slope Mowing Able
|
-60° ~ 90°
|
|
|
||
|
3-Point Hitch
|
Cat 1 (Cat 2 Bushings Included)
|
|
|
||
|
PTO Shaft Clockwise
|
540 RPM
1500mm / 59inch |
|
|
||
|
PTO SShaft Length
|
|
|
|
||
|
Total Length Of Hydraulic Pipes
|
70/79/121/131inch
|
|
|
||
|
Working Efficiency Per Hour (Approx.)
|
5400 - 10800 m2 / 1.3 – 2.6acre
|
6200 - 12400 m2 / 1.5 – 3acre
|
7000 - 14000 m2 / 1.7 – 3.4acre
|
||
|
Drive System
|
3 Belt System
|
3 Belt System
|
4 Belt System
|
||
|
Tractor Engine Power, Recommended
|
30-40hp / 22-30KW
|
40-55hp / 30-41KW
|
45-60hp / 34-45KW
|
||
|
Material Strength Flail Shat Cover
|
4mm / 0.15inch
|
|
|
||
|
Material Strength Side Walls
|
6mm / 0.23inch
|
|
|
||
|
Painting
|
Powder Coating
|
|
|
||
|
Flail Form
|
Hammer (Y-Knives Available)
|
|
|
||
|
Number Of Flails (Separately Exchangable)
|
24
|
24
|
28
|
||
|
Weight Per Flail
|
800gr / 1.76lb
|
|
|
||
|
RPM Of Flail Shaft
|
2200
|
|
|
||
|
Transport Box (LxWxH)
|
142x92x82cm / 56x37x33inch
|
162x92x82cm / 64x37x33inch
|
182x92x82cm / 72x37x33inch
|
||
