Die cutting unit
1、The roller is plated with hard chrome on the surface of high quality steel, and the dynamic balance correction is to increase its operation stability and reliability.
2、Die cutting rollers and rubber pad rollers are of international standard size, and suitable template and rubber pad can be purchased anywhere in the country.
3、The gap between the die cutting roller and the rubber cushion roller is electrically adjusted, parameters can be set and adjustment data can be displayed.
4、The phase of die - cutting roller adopts three planets structure, high precision, large bearing capacity, stop, operation can be electric digital 360° adjustment.
5、The rubber pad roller is automatically lifted to reduce the abrasion when the paper feeding is stopped.
6、The rubber pad is made of polyurethane felt sleeve produced in Taiwan, which can achieve 100% cutting rate and smooth incision.
7、The replacement order of the rubber pad shall be subject to the loading and unloading operation manual of the rubber pad.
8、The rubber cushion roller adopts the mechanical CAM type left and right moving device, each knife is in a different position,effectively extending the service life of felt sleeve.
9、The cutter die roller can be adjusted by manual axial distance ±10mm.
10、Die cutting upper and lower roller diameter is different, but the two roller linear velocity is equal. Can control the die -cutting knife in the circular direction of infinite non - circular work, so that the wear of rubber sleeve more uniform.
11、Linear speed compensation device. When the diameter of the pad roller changes, the linear speed compensation device automatically tracks and compensates.No need to manually adjust the speed, to ensure that each batch of carton die-cutting size is exactly the same, while greatly extending the felt sleeve and knife mold life.
12、The pad roller automatic repair device can repair the worn felt sleeve for many times. The repaired felt sleeve is smooth and clean, maintaining the same performance as the new felt sleeve. Greatly improves the reuse rate of pad.
