Quick Details
-
Marketing Type:
-
New Product 2023
-
Production Capacity:
-
28 m/min
-
Power:
-
3.2 kW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
huashuo
-
Dimension(L*W*H):
-
1690x1000x1150 mm
-
Product name:
-
Mini Asphalt Paver
-
Max. Operating Mass:
-
530 kg
-
Length (max.):
-
2000 mm
-
Working Width (max.):
-
1000 mm
-
Working Width (min.):
-
250 mm
-
Front Wheels:
-
2 x Hydrostatically driven wheels, D400mm
-
Fuel volume:
-
4L
-
Hopper volume:
-
150L
-
DIMENSIONS:
-
1690*1000*1150mm
Quick Details
-
Max. Paving Thickness:
-
1000 mm
-
Weight:
-
260 kg, 260kg
-
Engine Brand:
-
HONDA
-
Marketing Type:
-
New Product 2023
-
Production Capacity:
-
28 m/min
-
Power:
-
3.2 kW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
huashuo
-
Dimension(L*W*H):
-
1690x1000x1150 mm
-
Product name:
-
Mini Asphalt Paver
-
Max. Operating Mass:
-
530 kg
-
Length (max.):
-
2000 mm
-
Working Width (max.):
-
1000 mm
-
Working Width (min.):
-
250 mm
-
Front Wheels:
-
2 x Hydrostatically driven wheels, D400mm
-
Fuel volume:
-
4L
-
Hopper volume:
-
150L
-
DIMENSIONS:
-
1690*1000*1150mm
Standard configuration
(1)Hydraulic bridge with dual-wheel drive, swiveling steering wheel.
(2)Forward and reverse handle control.
(3)Independent control of paving thickness with dual hydraulic cylinders on the left and right.
(4)Four selectable paving widths.
(5)Engine exhaust heating plate function.
(6)Detachable hopper.
(7)Handle-operated brake.
|
Technical Specifications
|
Value
|
|
Weight
|
|
|
Maximum Operating Weight
|
530 kg
|
|
Empty Weight
|
260 kg
|
|
Dimensions
|
|
|
Maximum Length
|
2000 mm
|
|
Transport Dimensions (LxWxH)
|
1690x1000x1150 mm
|
|
Maximum Working Width
|
1000 mm
|
|
Minimum Working Width
|
250 mm
|
|
Chassis
|
|
|
Front Drive Wheels
|
2x Hydraulic drive wheels, diameter 400mm
|
|
Rear Steering Wheel
|
1x Swivel wheel, diameter 260mm
|
|
Traction
|
|
|
Maximum Working Speed
|
28 m/min
|
|
Maximum Transport Speed
|
3.2 Km/H
|
|
Engine
|
|
|
Model
|
HONDA GXV160
|
|
Emission Standard
|
EPA
|
|
Rated Power
|
3.2 Kw
|
|
Specifications
|
Air-cooled single-cylinder gasoline engine
|
|
Number of Cylinders
|
1
|
|
Fuel Capacity
|
4 L
|
Product Advantages
Application
Small asphalt pavers find extensive applications in areas such as small roads, sidewalks, bicycle lanes, parking lots, and repair projects. Their portability, efficiency, and flexibility make them an ideal choice for various small and medium-sized road construction projects, as well as urban infrastructure, rural roads, and other small construction projects.
