Quick Details
-
Size:
-
1460*705*1120mm
-
Max load:
-
140kg
-
Max speed:
-
15km/h
-
Charger:
-
24V 5A/6A
-
Brake System:
-
electromagnetic brake
-
Charging time:
-
6-8h
-
Max climbing degree:
-
15°
Quick Details
-
Dimension:
-
1460*705*1120mm
-
Color:
-
Customized
-
Motor:
-
24V 1000W
-
Size:
-
1460*705*1120mm
-
Max load:
-
140kg
-
Max speed:
-
15km/h
-
Charger:
-
24V 5A/6A
-
Brake System:
-
electromagnetic brake
-
Charging time:
-
6-8h
-
Max climbing degree:
-
15°
Product Description
| Battery | 2X55AH | 2X75AH |
| Motor power | 24V 1000W | |
| Charger | 24V 5A | 24V 6A |
| Front Tire | 13*6.00-6 Penumatic | |
| Rear Tire | 13*6.00-6 Penumatic | |
| Max. climbing degree | 15° | |
| Max. speed (km/h) | 15km/h | |
| Max. loading weight | 140 kgs | |
| Travel Range | 45 km | 60km |
| Overall dimensions | 1460×705×1120mm | |
| Weight w/o battery | 55kg | |
| Total Weight w/Bat. | 86kg | 106kg |
| Turning Radius | 1.7m | |
| Ground Clearance | 110mm | |
| Drive System | 24V Sealed Mid Transaxle | |
| Brake System | electromagnetic brake | |
| Free Wheeling | Manual Electric | |
| Wheel Hub | Nylo | |
| Seating | 360° Swivel and Position Adjustment - Foldable seat w/ arm rest | |
| Qty/20' | 44pcs | |
| Qty/40'HQ | 88pcs | |
