The hose crimping machine is operated by hand pump, no power supply need.
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
400*300*400mm
-
Weight:
-
30
-
Power (kW):
-
0
-
Type:
-
Manual hose crimping machine
-
Crimping range:
-
1/4''-1''
-
Crimping force:
-
150T
-
Color:
-
Blue
-
Free dies:
-
8 sets
-
Scale accuracy:
-
0.01mm
-
Max opening:
-
20mm
-
Quality:
-
Top High
-
Application:
-
Crimping Hose Fittings
-
Feature:
-
Light Weight
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
MENSION
-
Voltage:
-
0
-
Dimension(L*W*H):
-
400*300*400mm
-
Weight:
-
30
-
Power (kW):
-
0
-
Type:
-
Manual hose crimping machine
-
Crimping range:
-
1/4''-1''
-
Crimping force:
-
150T
-
Color:
-
Blue
-
Free dies:
-
8 sets
-
Scale accuracy:
-
0.01mm
-
Max opening:
-
20mm
-
Quality:
-
Top High
-
Application:
-
Crimping Hose Fittings
-
Feature:
-
Light Weight
High Quality Manual Hydraulic Press Hose p16 1/8'' To 1'' Hydraulic Hose Crimping Machine For Fire Flexible Hose Pressing
Product Description
MS-P16HP Hydraulic Hose Crimping Machine.
Manual type MS-P16HP is widely used in the field where there is
no power supply
.
It has the capacity of crimping high pressure hose from 1/4 inch to 1 inch with standard seven die sets.
P16HP uses high quality hand pump, as optional choice it uses the world famous hydraulic hand pump ''
ENERPAC
'', to enable it work with high accuracy and high stability.
It has the advantage of
light weight
'' 30KG'' before fill oil, so it is easy to take to any place that need.
Specification
|
Type:
|
MS-P16HP
finn power manual hydraulic hose crimping machine
|
|
Crimping Range:
|
1/8''-1''
|
|
Crimping Force:
|
1500KN
|
|
Free Dies:
|
8 sets
|
|
Operate Mode:
|
Manual
|
|
Pump Type:
|
Hand Pump
|
|
Weight:
|
30KG
|
|
Dimension:
|
400*300*400mm
|
|
Hydraulic Oil:
|
T46 Telus or Equvalent
|
Details Images
Light Weight.
MS-P16HP is with 30KG light weight, can be take to any place that needed.
High Precision Micrometer.
MS-P16HP can crimp hose from 1/4'' to 1'', with standard 7 die sets. The crimping size is controlled by a high precision micrometer up to 0.01mm accuracy.
Crimping Reference Table.
MS-P16HP is offered with a crimping reference chart, to tell the user, especially the new user, how to choose the die sets. Each die set has its own crimping range, choose the proper die sets for the crimping piece, will get a better crimping effect. The grey part is not recommended.
Die sets.
The 7 sets dies are put into the box on the bottom of the machine. It make the user easier to store the die sets when it not been used.
High stability hydraulic pump.
.
MS-P16HP utilize famous ''
ENERPAC
'' manual hydraulic pump from USA as optional based on standard configuration. It has the advantage of:
1. Lightweight and compact design
2. Decreasing reinforced engineering plastic fuel tank and nylon encapsulated aluminum pump body corrosion.
3. Double speed operation, the handle stroke is reduced by 78% by single speed operation.
4. Handle labor, reduce operator labor intensity
5. With 4-way valve to operable double-acting cylinder
6. Chain handle and lightweight structure easy
7. Special handle guarantees operator safety
8. Built-in safety valve for overload protection
Tight Package.
MS-P16HP is tightly fasten on the bottom pallet.
Utilize plywood case as the final package, free fumigation for many countries, like Australia.
New hose crimping machine do not comes with hydraulic oil, users need to add new Telus T46 or equivalent hydraulic oil.
The working volume of the hydraulic pump is about 328mL. Add enough hydraulic oil to enable the machine can works well.
Application Field
Application of the hydraulic hose crimping machine.
MS-P16HP portable crimping machines are designed for field service when repairs must be made on-site.
It can crimp hydraulic hose from 1/4'' to 1''. Also capable of crimping small tubes and pipes, wires and cable, etc.
They are used globally in such industries as hydraulic hoses, automotive components, construction equipment, heavy machinery, rail road, marine, electric power transmission, industrial hoses and tube, pipe, wire and cable industry, etc.
