Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Growatt
-
Model Number:
-
SPH3000-6000 BL-UP
-
Input Voltage:
-
150V-550V /360V
-
Output Voltage:
-
230V/240V (180Vac-270Vac)
-
Output Current:
-
16A-27A
-
Output Frequency:
-
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
-
Size:
-
450*560*180mm
-
Certificate:
-
ISO CE TUV
-
Warranty:
-
5-10
-
Weight:
-
27 kg
-
Displacement power factor:
-
0.8 leading ~ 0.8 lagging
-
Standard warranty [years]:
-
5-10
-
Topology:
-
Transformerless
-
Cooling concept:
-
Natural convection
-
Protection degree:
-
IP65
-
Type of battery:
-
Lithium /Lead-acid
-
DC reverse polarity protection:
-
Yes
-
Output over current protection:
-
Yes
-
Grid monitoring:
-
Yes
-
DC switch rating for each MPPT:
-
Yes
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
97.2%
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Growatt
-
Model Number:
-
SPH3000-6000 BL-UP
-
Input Voltage:
-
150V-550V /360V
-
Output Voltage:
-
230V/240V (180Vac-270Vac)
-
Output Current:
-
16A-27A
-
Output Frequency:
-
50Hz/60Hz (45Hz-55Hz/55Hz-65Hz)
-
Size:
-
450*560*180mm
-
Certificate:
-
ISO CE TUV
-
Warranty:
-
5-10
-
Weight:
-
27 kg
-
Displacement power factor:
-
0.8 leading ~ 0.8 lagging
-
Standard warranty [years]:
-
5-10
-
Topology:
-
Transformerless
-
Cooling concept:
-
Natural convection
-
Protection degree:
-
IP65
-
Type of battery:
-
Lithium /Lead-acid
-
DC reverse polarity protection:
-
Yes
-
Output over current protection:
-
Yes
-
Grid monitoring:
-
Yes
-
DC switch rating for each MPPT:
-
Yes
Product Description
Smart Monitoring System
Technical Specifications
|
Model
|
SPH3000TL
BL-UP
|
SPH3600TL
BL-UP
|
SPH4000TL
BL-UP
|
SPH4600TL
BL-UP
|
SPH5000TL
BL-UP
|
SPH6000TL
BL-UP
|
||||||
|
Input Data (DC)
|
|
|
|
|
|
|
||||||
|
Max. recommended PV power
(for module STC)
|
6600W
|
6600W
|
6600W
|
8000W
|
8000W
|
8000W
|
||||||
|
Max. DC voltage
|
550V
|
550V
|
550V
|
550V
|
550V
|
550V
|
||||||
|
Start voltage
|
150V
|
|
|
|
|
|
||||||
|
MPP voltage range
|
150V-550V /360V
|
|
80V-500V
|
80V-550V
|
80V-550V
|
80V-550V
|
||||||
|
No. of MPP trackers
|
2
|
|
|
|
|
|
||||||
|
No. of PV strings per MPP tracker
|
1
|
|
|
|
|
|
||||||
|
Max. input current per MPP tracker
|
12A
|
|
|
|
|
|
||||||
|
Max. short-circuit current per MPP tracker
|
15A
|
|
|
|
|
|
||||||
|
Output data (AC)
|
|
|
|
|
|
|
||||||
|
AC nominal power
|
3000W
|
3680W
|
4000W
|
4600W
|
5000W
|
6000W
|
||||||
|
Max. AC apparent power
|
3000VA
|
3680VA
|
4000VA
|
4600VA
|
5000VA
|
6000VA
|
||||||
|
Nominal AC voltage（range*)
|
230V/240V (180Vac-270Vac)
|
|
|
|
|
|
||||||
|
AC grid frequency（range*)
|
50/60 Hz (45-55Hz/55-65 Hz)
|
|
|
|
|
|
||||||
|
Max. output current
|
16A
|
16A
|
22A
|
22A
|
22A
|
27A
|
||||||
|
Adjustable power factor
|
0.8leading…0.8lagging
|
|
|
|
|
|
||||||
|
THDi
|
<3%
|
|
|
|
|
|
||||||
|
AC grid connection type
|
Single phase
|
|
|
|
|
|
||||||
|
Battery data (DC)
|
|
|
|
|
|
|
||||||
|
Battery voltage range
|
42~59V
|
|
|
|
|
|
||||||
|
Max charging and discharging current
|
75A
|
|
|
|
|
|
||||||
|
Continuous charging and discharging power
|
3600W
|
|
|
|
|
|
||||||
|
Type of battery
|
Lithium /Lead-acid
|
|
|
|
|
|
||||||
|
Backup power(AC)
|
|
|
|
|
|
|
||||||
|
Max. AC output power
|
3000W
|
3680W
|
4000W
|
4600W
|
5000W
|
6000W
|
||||||
|
Max. AC apparent power
|
3000VA
|
3680VA
|
4000VA
|
4600VA
|
5000VA
|
6000VA
|
||||||
|
Max. output current
|
16A
|
16A
|
22A
|
22A
|
22A
|
27A
|
||||||
|
Nominal AC output voltage
|
230VAC
|
|
|
|
|
|
||||||
|
Nominal AC output frequency
|
50/60HZ
|
|
|
|
|
|
||||||
|
THDv
|
<3%
|
|
|
|
|
|
||||||
|
Switch time
|
<10ms
|
|
|
|
|
|
||||||
|
Efficiency
|
|
|
|
|
|
|
||||||
|
Max.efficiency
|
97.2%
|
97.2%
|
97.2%
|
97.3%
|
97.3%
|
97.5%
|
||||||
|
European efficiency
|
96.9%
|
96.9%
|
96.9%
|
97.0%
|
97.0%
|
97.1%
|
||||||
|
Protection Devices
|
|
|
|
|
|
|
||||||
|
DC reverse polarity protection
|
yes
|
|
|
|
|
|
||||||
|
DC switch
|
yes
|
|
|
|
|
|
||||||
|
AC/DC surge protection
|
yes
|
|
|
|
|
|
||||||
|
Insulation resistance monitoring
|
yes
|
|
|
|
|
|
||||||
|
AC short-circuit protection
|
yes
|
|
|
|
|
|
||||||
|
Ground fault monitoring
|
yes
|
|
|
|
|
|
||||||
|
Grid monitoring
|
yes
|
|
|
|
|
|
||||||
|
Anti-islanding protection
|
yes
|
|
|
|
|
|
||||||
|
Residual-current monitoring unit
|
yes
|
|
|
|
|
|
||||||
|
Battery reverse protection
|
yes
|
|
|
|
|
|
||||||
|
General Data
|
|
|
|
|
|
|
||||||
|
Dimensions (W / H / D)
|
450/560/180mm
|
|
|
|
|
|
||||||
|
Weight
|
27kg
|
|
|
|
|
|
||||||
|
Operating temperature range
|
–25°C ... +60°C
|
|
|
|
|
|
||||||
|
Noise emission (typical)
|
≤25 dB(A)
|
|
|
|
|
|
||||||
|
Nighttime power consumption
|
< 7W
|
|
|
|
|
|
||||||
|
Topology
|
Transformerless
|
|
|
|
|
|
||||||
|
Cooling
|
Natural convection
|
|
|
|
|
|
||||||
|
Protection degree
|
IP65
|
|
|
|
|
|
||||||
|
Relative humidity
|
0-100%
|
|
|
|
|
|
||||||
|
Altitude
|
2000m
|
|
|
|
|
|
||||||
|
DC connection
|
H4/MC4(Optional)
|
|
|
|
|
|
||||||
|
AC connection
|
Connector
|
|
|
|
|
|
||||||
|
Display
|
LCD+LED
|
|
|
|
|
|
||||||
|
IInterfaces: RS232/RS485/CAN/USB
|
Yes
|
|
|
|
|
|
||||||
|
Monitor : RF/WIFI/GPRS
|
Optional
|
|
|
|
|
|
||||||
|
Warranty: 5 years / 10 years
|
Yes /Optional
|
|
|
|
|
|
||||||
