Quick Details
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
1200 kg
-
Bucket capacity:
-
0.12cbm
-
Marketing Type:
-
New Product 2023
-
Height at Maximum Extension/mm:
-
2450
-
Height To the the bucket pin /mm:
-
1870
-
Vehicle height:
-
1350
-
Length With standard bucket /mm:
-
2206
-
Maximum height unloading Angle:
-
34
-
Dumping Height/mm:
-
1510
-
Discharge Distance/mm:
-
450
-
Maximum Operating Capacity/Kg:
-
400
-
Rated Operating Capacity/Kg:
-
300
-
System Operating Pressure /bar:
-
17-21
Quick Details
-
Engine Brand:
-
Other
-
Power:
-
13.5kw
-
Brand Name:
-
Hightop
-
Place of Origin:
-
Shandong, China
-
Machine Weight:
-
1200 kg
-
Bucket capacity:
-
0.12cbm
-
Marketing Type:
-
New Product 2023
-
Height at Maximum Extension/mm:
-
2450
-
Height To the the bucket pin /mm:
-
1870
-
Vehicle height:
-
1350
-
Length With standard bucket /mm:
-
2206
-
Maximum height unloading Angle:
-
34
-
Dumping Height/mm:
-
1510
-
Discharge Distance/mm:
-
450
-
Maximum Operating Capacity/Kg:
-
400
-
Rated Operating Capacity/Kg:
-
300
-
System Operating Pressure /bar:
-
17-21
Product Description
Mini Skid Steer Loader
Wheel type
Crawler type
Electric type
Remote control
color optional:
yellow
,
white
,
green
,
etc...
gasoline/diesel
engine optional
Detail presentation
Specification
|
ITEMS
|
SPECIFICATIONS
|
ITEMS
|
SPECIFICATIONS
|
|
Engine Brand
|
LONCIN/RATO/KOOP
|
Height at Maximum Extension/mm
|
2450
|
|
Rated Power/KW
|
15-18KW
|
Height To the the bucket pin /mm
|
1870
|
|
Rated Speed/rpm
|
3600
|
Vehicle height
|
1350
|
|
Number of cylinders
|
2
|
Maximum Height as Lay the bucket flat/mm
|
1810
|
|
Air intake way
|
Naturally Aspirated
|
Total length without appendages/mm
|
1680
|
|
Displacement/cc
|
639
|
Length With standard bucket /mm
|
2206
|
|
Emissions Standards
|
EUR 5
|
Maximum height unloading Angle
|
34
|
|
Rated Operating Capacity/Kg
|
300
|
Dumping Height/mm
|
1510
|
|
Maximum Operating Capacity/Kg
|
400
|
Discharge Distance/mm
|
450
|
|
Maximum Breakout Force/KN
|
450
|
The flip Angle of the bucket on the ground
|
27
|
|
Bucket Capacity/m3
|
0.12
|
Bucket flip Angle at highest Pos.
|
114
|
|
Driving Speed/ km/h
|
0-6
|
Wheel Base/mm
|
850
|
|
Total Cycling Time/s
|
9
|
Ground Clearance/mm
|
150
|
|
System Operating Pressure /bar
|
17-21
|
Tail Length/mm
|
280
|
|
Fuel Tank Capcity/L
|
10
|
Wheel base
(standard tire) /mm |
720
|
|
Operating Weight/Kg
|
1200
|
Vehicle width
(standard tire) /mm |
960
|
|
Tyre Size
|
18*72
|
Bucket width/mm
|
1000
|
Packing & Delivery
Packed in Wooden case
