Quick Details
-
Rated Voltage:
-
24
-
Rated Current:
-
10
-
Series:
-
DSBF
-
Package:
-
Bulk
-
Product Status:
-
Active
-
Type:
-
Linear Actuator
-
Construction:
-
Square Cylinder
-
Stroke Length:
-
250.00mm
-
Operation:
-
Double Acting
-
Operating Pressure:
-
5.8 ~ 174 PS
-
Features:
-
ISO Standardized
-
Operating Temperature:
-
-20°C ~ 80°C
Quick Details
-
Brand Name:
-
ZHFESTO
-
Place of Origin:
-
Tianjin, China
-
Model Number:
-
DSBC
-
Rated Voltage:
-
24
-
Rated Current:
-
10
-
Series:
-
DSBF
-
Package:
-
Bulk
-
Product Status:
-
Active
-
Type:
-
Linear Actuator
-
Construction:
-
Square Cylinder
-
Stroke Length:
-
250.00mm
-
Operation:
-
Double Acting
-
Operating Pressure:
-
5.8 ~ 174 PS
-
Features:
-
ISO Standardized
-
Operating Temperature:
-
-20°C ~ 80°C
ORIGINAL AND NEW DSBA-F-80-500-CA DSNU-12-10-P-A 19189 AEVUZ-32-25-A-P-A157276 FESTO Air Cylinder
Product details
| Series | DSBF |
| Package | Bulk |
| Product Status | Active |
| Type | Linear Actuator |
| Construction | Square Cylinder |
| Stroke Length | 250.00mm |
| Operation | Double Acting |
| Operating Pressure | 5.8 ~ 174 PS |
| Features | ISO Standardized |
| Operating Temperature | -20°C ~ 80°C |
| Product Keywords | DSBA-F-80-500-CA,DSNU-12-10-P-A 19189,AEVUZ-32-25-A-P-A157276 |
Cylinders
Festo piston rod cylinders are pneumatic drives for executing linear movements. They are available as round cylinders, profile cylinders, compact cylinders, short-stroke cylinders, flat cylinders, miniature cylinders, screw-in or stainless-steel cylinders; and, depending on the piston diameter, they can provide thrust forces of up to 50 kN at 6 bar. Selected types in accordance with the ATEX directive are also suitable for explosive atmospheres or are made of corrosion-resistant stainless steel and therefore particularly easy to clean.
Round cylinders
Thanks to their round design, round cylinders can even be installed in tight spaces. What all round cylinders have in common is excellent operational performance, a long service life, and quick and easy installation. The piston rod cylinders are available both as double-acting and single-acting actuators, as well as pneumatic cylinders according to standard ISO 6432.
Compact, short-stroke and flat cylinders.
Compact cylinders are pneumatic cylinders with an installation length that is extremely compact in relation to the stroke length. They are typically used when space is extremely limited and the requirements for lateral loads are low. The compact cylinders belong to the group of directly mounted cylinders and are usually installed without any specific mounting accessories. Short-stroke cylinders start from a stroke of 2.5 mm and flat cylinders are characterised – as the name suggests – by a particularly flat design with an oval piston that is protected against rotation.
ISO 15552 (ISO 6431, VDMA 24562)
- Self-adjusting pneumatic end-position cushioning saves time during commissioning and adapts optimally to load and speed changes
- Standard profile with two sensor slots
- Wide range of variants for customized applications
- Comprehensive range of mounting accessories for just about every type of installation
- Magnetic piston for position sensing
- Variants recommended for production facilities for the manufacture of lithium-ion batteries
