Quick Details
-
Model Number:
-
HD-02A
-
Input:
-
2*HDMI, 1*3.5mm Audio, 1*Microphone
-
Output:
-
1*HDMI, 1*USB 3.0, 1*Headphone 3.5mm
-
USB-C:
-
USB 3.0, 5Gb/s
-
Capture Standard:
-
UVC/UAC
-
Input Format:
-
HDMI2.0
-
Capture Video Format:
-
RGB, YUY2, NV12
-
Input Resolution:
-
Max. 4K@60Hz
-
Capture Resolution:
-
Max. 1080P@60Hz
-
HDCP:
-
Support
-
Keywords:
-
Audio Vedio Capture Card
Quick Details
-
Power Supply:
-
110V AC, 220V AC, 5V DC/AC
-
Input Interface:
-
HDMI
-
Video Format:
-
YUY2, RGB, NV12
-
Model Number:
-
HD-02A
-
Input:
-
2*HDMI, 1*3.5mm Audio, 1*Microphone
-
Output:
-
1*HDMI, 1*USB 3.0, 1*Headphone 3.5mm
-
USB-C:
-
USB 3.0, 5Gb/s
-
Capture Standard:
-
UVC/UAC
-
Input Format:
-
HDMI2.0
-
Capture Video Format:
-
RGB, YUY2, NV12
-
Input Resolution:
-
Max. 4K@60Hz
-
Capture Resolution:
-
Max. 1080P@60Hz
-
HDCP:
-
Support
-
Keywords:
-
Audio Vedio Capture Card
USB 3.0 4K 1080P Streaming OBS Capturing Gaming Live Recording HDR Dual HDMI Video Capture Card HDMI to USB
Introduction:
The USB 3.0 dual channel HDMI video capture card can simultaneously capture dual 4K HDMI input video signals, while supporting HDMI 1080P loop out, compatible with Windows7/8/8.1/10/11, Linux and Mac OS, and backward compatible with USB2.0, by USB 3.0/Type-C interface to connect to the computer, through play/capture software to achieve preview, recording, live streaming and other functions.
Features:
1. The input can support up to 4K@60Hz, loop out and capture recording resolution up to 1080P@60Hz
2. Recording video format support RGB/24bit, YUY2/
3. Support UAC / UVC protocol, support for 48KHz audio sampling rate.
4. No driver required, compatible with Windows 7/8/8.1/10/11, Linux and Mac OS.
5. Support HDR color input, loop out and capture.
6. Support microphoneaudio input, line audio input, and headphone monitoring.
7. Low power consumption, ultra-low latency, clearer picture quality, RGB color range 0~255.
The USB 3.0 dual channel HDMI video capture card can simultaneously capture dual 4K HDMI input video signals, while supporting HDMI 1080P loop out, compatible with Windows7/8/8.1/10/11, Linux and Mac OS, and backward compatible with USB2.0, by USB 3.0/Type-C interface to connect to the computer, through play/capture software to achieve preview, recording, live streaming and other functions.
Features:
1. The input can support up to 4K@60Hz, loop out and capture recording resolution up to 1080P@60Hz
2. Recording video format support RGB/24bit, YUY2/
3. Support UAC / UVC protocol, support for 48KHz audio sampling rate.
4. No driver required, compatible with Windows 7/8/8.1/10/11, Linux and Mac OS.
5. Support HDR color input, loop out and capture.
6. Support microphoneaudio input, line audio input, and headphone monitoring.
7. Low power consumption, ultra-low latency, clearer picture quality, RGB color range 0~255.
Specification
|
item
|
value
|
|
Private Mold
|
Yes
|
|
Input Interface
|
HDMI
|
|
Output Interface
|
USB, HDMI
|
|
Support Systerm
|
XSplit, QuickTime Player, Skype, DirectSound, Adobe Flash Media Live Encoder, DirectShow, OBS, OS X, Xbox, PlayStation 4, Windows 10, Android 5.0 or above
|
|
Resolution
|
800x600, 640x480, 1920x1080
|
|
Video Format
|
YUY2, RGB, NV12
|
|
Capture Format
|
MP4
|
|
Power Supply
|
110V AC, 220V AC, 5V DC/AC
|
|
Model Number
|
HD-02A
|
|
Input
|
2*HDMI, 1*3.5mm Audio, 1*Microphone
|
|
Output
|
1*HDMI, 1*USB 3.0, 1*Headphone 3.5mm
|
|
USB-C
|
USB 3.0, 5Gb/s
|
|
Capture Standard
|
UVC/UAC
|
|
Input Format
|
HDMI2.0
|
|
Capture Video Format
|
RGB, YUY2, NV12
|
|
Input Resolution
|
Max. 4K@60Hz
|
|
Capture Resolution
|
Max. 1080P@60Hz
|
|
HDCP
|
Support
|
|
Keywords
|
Audio Vedio Capture Card
|
