Safe and reliable, High energy, Low consumption, adjusted speed motor
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
XINYU
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
400*500*5000mm
-
Marketing Type:
-
New Product 2023
-
Weight (KG):
-
120 kg
-
Product name:
-
Z Type Bucket Elevator
-
Frame Material:
-
SUS304/Carbon Steel
-
Motor:
-
Variable Speed
-
Keyword:
-
bucket elevator conveyor
-
Feature:
-
High Efficiency
-
Installation:
-
Under Engineer's Guide
-
service after sale:
-
provide
-
Application:
-
powder animal feed pellet grainule
-
Name:
-
bucket elevator
-
Usage:
-
Material Conveying
Quick Details
-
Power:
-
5.5kw
-
Warranty:
-
1 Year
-
Width or Diameter:
-
300mm
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
XINYU
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
400*500*5000mm
-
Marketing Type:
-
New Product 2023
-
Weight (KG):
-
120 kg
-
Product name:
-
Z Type Bucket Elevator
-
Frame Material:
-
SUS304/Carbon Steel
-
Motor:
-
Variable Speed
-
Keyword:
-
bucket elevator conveyor
-
Feature:
-
High Efficiency
-
Installation:
-
Under Engineer's Guide
-
service after sale:
-
provide
-
Application:
-
powder animal feed pellet grainule
-
Name:
-
bucket elevator
-
Usage:
-
Material Conveying
Application
It is widely applied in vast industry, chemical industry, building industry, mine, grain, food, fodder, plastic.
This lifting conveyor is designed for transporting crushed material, small blocky materials, it is perfectly applicated in vertical transferring granule, powder, grain, starch, food, coal, cement, gravel, sand, clay, broken ore, fertilizer, feed, etc
This lifting conveyor is designed for transporting crushed material, small blocky materials, it is perfectly applicated in vertical transferring granule, powder, grain, starch, food, coal, cement, gravel, sand, clay, broken ore, fertilizer, feed, etc
Features
more Conveyor types
Two materials
Stainless Steel (Food Industry)
Carbon Steel (non-food industry)
1.The high-efficiency vertical bucket elevator for sale can convey both general powders, small granule materials, and also rubbed materials.
2.The high-efficiency vertical bucket elevator for sale is in good sealing, little environmental pollution.
3.The high-efficiency vertical bucket elevator for sale operation is satisfactory reliability, lift high altitude.
4.Low power required(effective inflow feeding, induction material handling)
5.The high-efficiency vertical bucket elevator for sale is much reliable in quality.
Product Parameter
|
Technical Parameters of Vertical Bucket Elevator Conveyor Machine
|
|
|
|
|
|
|||||
|
Model
|
TH-BBC-11
|
TH-BBC-13
|
TH-BBC-18
|
TH-BBC-23
|
TH-BBC-28
|
|||||
|
Power supply(KW)
|
2.2
|
3
|
4
|
5.5
|
7.5
|
|||||
|
Machine weight(Kg)
|
620
|
720
|
820
|
860
|
960
|
|||||
|
Bucket width(cm)
|
11
|
13
|
18
|
23
|
28
|
|||||
|
Conveying capacity
|
3t-5t/h
|
4t-6t/h
|
6t-10t/h
|
10t-20t/h
|
20t-40t/h
|
|||||
|
Machine material
|
Stainless steel 304/Carbon steel for option
|
|
|
|
|
|||||
|
Bucket material
|
Stainless steel 304/Carbon steel/ HDPE for option
|
|
|
|
|
|||||
|
Linear speed
|
2.5-3m/s
|
|
|
|
|
|||||
|
Lifting height
|
From 4m to 30m, Customized for practice
|
|
|
|
|
|||||
Product Details
* Famous brand motor, longer life
*
Big storage hopper
Our storage hopper and conveyor Height can be customize.
*
Electric box
VFD control speed, and easy to control.
Voltage: 380V/ 208V /120V/240V OPTION 50HZ /60HZ OPTION
Voltage: 380V/ 208V /120V/240V OPTION 50HZ /60HZ OPTION
*
Bucket hopper
Bucket hopper volume :0.8L,2L,4L,10L
Bucket hopper material: 304SS, Food grade plastics
Bucket can be removed, and it is convenient to clean
Bucket hopper material: 304SS, Food grade plastics
Bucket can be removed, and it is convenient to clean
*
Retaining ring
Our bucket conveyor have 8 retaining rings , and it can help customer to remove more
Machine Display
Certifications
Our Advantages
Product packaging
Exhibition
Why Choose Us
How about price of this product?
-- We can give the lowest price than market one because we are factory machinery.
-- We do quotation as soon as possible for any customer.
-- Discount can be given according to quantity.
What is the MOQ?
-- 1 set.
If you can be custom-made?
-- We can make products according to customer's requirements.
What is the voltage?
-- 380V 50hz 3 phase or any other voltage according to client's requirement.
