Quick Details
-
Brand Name:
-
Guohui
-
Model Number:
-
GH-LKE
-
Color Temperature(CCT):
-
2700K-6500K
-
Beam Angle(°):
-
TYPE I, TYPE II, TYPE III
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
AC100-305V
-
Lamp Luminous Flux(lm):
-
13400
-
Working Temperature(℃):
-
20 - 60
-
Product Weight（kg）:
-
22
-
Product Name:
-
solar street lights
-
Solar panel:
-
18V/100W Mono-crystalline
-
Battery:
-
Lithium LifePO4 battery 12.8V,42AH
-
LEDs:
-
Original chip 2835
-
Light effiency:
-
170LM/W
-
Controller:
-
MPPT
-
Control method:
-
Motion sensor + Time control+ Smart control
-
Discharge time:
-
induction mode>48H, full power>14H
-
Installation height:
-
10-12M
Quick Details
-
Warranty(Year):
-
3-Year
-
Lighting solutions service:
-
Lighting and circuitry design, DIALux evo layout, LitePro DLX layout
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Guohui
-
Model Number:
-
GH-LKE
-
Color Temperature(CCT):
-
2700K-6500K
-
Beam Angle(°):
-
TYPE I, TYPE II, TYPE III
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
AC100-305V
-
Lamp Luminous Flux(lm):
-
13400
-
Working Temperature(℃):
-
20 - 60
-
Product Weight（kg）:
-
22
-
Product Name:
-
solar street lights
-
Solar panel:
-
18V/100W Mono-crystalline
-
Battery:
-
Lithium LifePO4 battery 12.8V,42AH
-
LEDs:
-
Original chip 2835
-
Light effiency:
-
170LM/W
-
Controller:
-
MPPT
-
Control method:
-
Motion sensor + Time control+ Smart control
-
Discharge time:
-
induction mode>48H, full power>14H
-
Installation height:
-
10-12M
Product Description
Detailed Images
High thermal conductivity, low light decay, pure light color, no ghosting, light efficiency up to 200lm/w
The battery can be replaced. Long lasting can support 4-7 rainy days. 2500 times charge and discharge at 80% DOD battery
Intelligent Controller
MPPT maximum power tracking technology, with tracking efficiency up to 99.5%. And charging efficiency up to 96%. Intelligent power regulation and automatic load. Power regulation make the operation of the whole system more efficient, energy-saving and stable.
Using anti-oxidation 6063 die-cast aluminum shell, high hardness, fast heat dissipation, thick anti-corrosion paint treatment.
High temperature protection system to protect batteries in hot weather.
IP66 is safe and waterproof, with no risk of leakage, anti-corrosion and rust prevention.
|
Product Number
|
20w 30w 40w 50w 60w 80w 100w led pole all-in-one solar panel hybrid solar street light hybrid solar wind street light
|
|
|
|
|||
|
Input Power
|
20W~100W
|
|
|
|
|||
|
Led Chips
|
SMD 3030/SMD5050
|
|
|
|
|||
|
Light Effiency
|
210LM/W
|
|
|
|
|||
|
Input Voltage
|
AC100-305V
|
Frequency
|
50/60HZ
|
|
|||
|
Power Factory
|
PF>0.95
|
CCT
|
2700-6500k or customized
|
|
|||
|
Power Supply
|
Battery
|
CRI
|
>80
|
|
|||
|
Production Sizes
|
635*346*65mm ~ 1655*346*65MM
|
Packing Sizes
|
675*380*85mm ~1695*380*85MM
|
|
|||
|
Installation height
|
4-10 m
|
Gross weight
|
5KG~21KG
|
|
|||
|
Lamp Boady Color
|
Black/Silver
|
|
|
|
|||
|
Power Cable
|
Brown L firewire
|
|
|
|
|||
|
|
Yellow Green G ground
|
|
|
|
|||
|
|
Blue N zero Line
|
|
|
|
|||
|
IP grade
|
IP65 waterproof
|
Material
|
Fin 1060 pure Aluminum
|
|
|||
|
Lifetime
|
50000 hours
|
Temperature
|
-40-+65 degree
|
|
|||
|
Certificate
|
CE ROHS CCC LVD
|
Warranty
|
3 years
|
|
|||
Package Details
|
Power
|
Product Size
|
Net Weight
|
Gross Weight
|
Packing Size
|
|
20W
|
635*346*65mm
|
4.5KG
|
10KG
|
675*380*85mm
|
|
30W
|
835*346*65mm
|
|
|
675*380*85mm
|
|
40W
|
835*346*65mm
|
|
|
675*380*85mm
|
|
60W
|
835*346*65mm
|
|
|
675*380*85mm
|
|
80W
|
835*346*65mm
|
|
|
675*380*85mm
|
Related Products
Company Introduction
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new light with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
OEM and ODM is high welcome! Our factory also can customize with client's requirments.
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new light with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
OEM and ODM is high welcome! Our factory also can customize with client's requirments.
