Quick Details
-
Brand Name:
-
DTEC, DTEC
-
Model Number:
-
RL12200, LFP12-4~LFP12-400;LFP24-50~LFP24-200
-
Place of Origin:
-
Shenzhou,China, Shenzhou, China
-
Weight:
-
27kg, 13.6kg-41kg
-
The charging ratio:
-
95%
-
The discharge rate:
-
90%
-
Keywords:
-
12V Lithium Ion lifepo4 Battery Pack
-
Maximum Charging Current:
-
0.8C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
>5000 cycles @0.5C / 50%DOD
Quick Details
-
Storage Type:
-
Dry storage
-
Anode Material:
-
LFP
-
Application:
-
Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Electric Forklifts
-
Brand Name:
-
DTEC, DTEC
-
Model Number:
-
RL12200, LFP12-4~LFP12-400;LFP24-50~LFP24-200
-
Place of Origin:
-
Shenzhou,China, Shenzhou, China
-
Weight:
-
27kg, 13.6kg-41kg
-
The charging ratio:
-
95%
-
The discharge rate:
-
90%
-
Keywords:
-
12V Lithium Ion lifepo4 Battery Pack
-
Maximum Charging Current:
-
0.8C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
>5000 cycles @0.5C / 50%DOD
Products Description
|
Capacity
|
100Ah
|
200Ah
|
300Ah
|
400Ah
|
500Ah
|
||||
|
Usable Capacity(Wh)
|
1280
|
2560
|
3840
|
5120
|
6400
|
||||
|
Working Temperature ℃
|
-20~55
|
-20~55
|
-20~55
|
-20~55
|
-20~55
|
||||
|
Size
|
Customized to your requirements
|
|
|
|
|
||||
|
Cycle Life
|
4000 times (20 Years Design Life)
|
|
|
|
|
||||
|
Warranty
|
5 Years
|
|
|
|
|
||||
|
Application
|
RV
|
Touring car
|
Camper
|
Marine
|
Solar system
|
||||
|
Nominal Voltage
|
12.8V
|
25.6V
|
|
|
Nominal Capacity
|
4-400AH
|
50-200AH
|
|
|
Charge Voltage
|
14.2~14.6V
|
28.4~29.2V
|
|
|
Charge Cut-off Voltage
|
14.6V±0.2V
|
29.2±0.2V
|
|
|
Discharge Cut-off Voltage
|
10V±0.5V
|
20V±0.5V
|
|
|
Recommended Charge Current
|
0.2C
|
|
|
|
Max. Charge Current
|
0.5C
|
|
|
|
Max. Continuous Discharge Current
|
1C
|
|
|
|
BMS
|
Integrated
|
|
|
|
Cycle Life
|
>5000 cycles @0.5C / 50%DOD
|
|
|
|
Months Self Discharge
|
<3%
|
|
|
|
Efficiency of Charge
|
100% @0.5C
|
|
|
|
Efficiency of Discharg
|
96~99% @0.5C
|
|
|
|
Charge Temperature
|
0°C~55°C @60±25% Relative Humidity
|
|
|
|
Discharge Temperature
|
-20°C~60°C @60±25% Relative Humidity
|
|
|
|
Storage Temperature
|
-20°C~45°C @60±25% Relative Humidity
|
|
|
|
Protection Class
|
IP65
|
|
|
|
Maximum Modules in Series
|
4
|
|
|
|
Monitoring Option
|
Bluetooth with Smartphone App
|
|
|
Details Images
Reliable ABS Case(resistance to heat and shock)M8
Terminal (Superb conductivity)
Durable Handle (Easy to carry and remove)
Durable Handle (Easy to carry and remove)
