Trina Solar has recently built three Vertex Super Factories in Yiwu, Zhejiang, as well as Suqian and Yancheng in Jiangsu, China.By
the end of 2020, Trina Solar will see its 210mm Vertex module production capacity exceeding 22GW, and will further shoot over 50GW in 2021 across the globe.
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 years linear power output warranty, 25 Years
-
Brand Name:
-
Trina
-
Model Number:
-
Trina DE09R.05 405-425w
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1762*1134*30 mm
-
Product name:
-
solar panels system
-
Application:
-
Solar Power System
-
Solar cell:
-
210*210mm
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
23.5kg
-
Connector:
-
Compatible Connector
-
Keyword:
-
Pv Module
-
Certificate:
-
TUV/CE/IEC61215/IEC61730/ISO
Quick Details
-
Cell size:
-
182*210mm
-
Type:
-
Half Cell, All Black
-
Panel Efficiency:
-
20.3%~21.3%
-
Warranty:
-
25 years linear power output warranty, 25 Years
-
Brand Name:
-
Trina
-
Model Number:
-
Trina DE09R.05 405-425w
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1762*1134*30 mm
-
Product name:
-
solar panels system
-
Application:
-
Solar Power System
-
Solar cell:
-
210*210mm
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
23.5kg
-
Connector:
-
Compatible Connector
-
Keyword:
-
Pv Module
-
Certificate:
-
TUV/CE/IEC61215/IEC61730/ISO
Product Description
Electrical Data
|
ELECTRICAL DATA (STC)
|
TSM-405 DE09R.05
|
TSM-410 DE09R.05
|
TSM-415 DE09R.05
|
TSM-420 DE09R.05
|
TSM-425 DE09R.05
|
||||
|
Peak Power Watts-PMAX (Wp)*
|
405
|
410
|
415
|
420
|
425
|
||||
|
Power Tolerance-PMAX (W)
|
0~+5
|
|
|
|
|
||||
|
Maximum Power Voltage-VMPP (V)
|
40.6
|
40.8
|
41.0
|
41.3
|
41.5
|
||||
|
Maximum Power Current-lMPP (A)
|
9.99
|
10.05
|
10.11
|
10.17
|
10.24
|
||||
|
Open Circuit Voltage-Voc (V)
|
49.0
|
49.2
|
49.4
|
49.7
|
49.9
|
||||
|
Short Circuit Current-Isc (A)
|
10.52
|
10.58
|
10.64
|
10.69
|
10.74
|
||||
|
Module Efficiency ηm (%)
|
20.3
|
20.5
|
20.8
|
21.0
|
21.3
|
||||
|
Brand Name
|
Trina
|
|
Model Number
|
DE09R.05 405-425w
|
|
Cell size
|
210mmx210mm
|
|
Type
|
PERC, Half Cell, All Black
|
|
Panel Dimensions
|
1762*1134*30 mm
|
|
Panel Efficiency
|
21.3%
|
|
Certificate
|
CE TUV IEC
|
|
Warranty
|
30 years
|
|
Product name
|
Mono Black Solar Panel
|
|
Solar cell
|
Monocrystalline Silicon Cells
|
|
Junction Box
|
IP68 Rated
|
|
Frame
|
Anodized Aluminium Alloy
|
|
Connector
|
MC4 Compatible Connector
|
|
Front Glass
|
3.2mm High Transparency Tempered Glass
|
|
Operate Temperature
|
40 ~+85
|
|
Power Tolerance
|
0~+5W
|
|
Output cable
|
TUV1*4.0mm2
|
|
Application
|
Solar Home System
|
Details Images
Trina Factory
Super Factory, Super Technologies Low voltage, high-string-power design Multi-busbar technology with precisions in millimeters
Super Factory, Super IntelligenceHigh Level of Automation and Highly Efficient Productivity
Sharing Data with Customers for Smart Manufacture in the 600W+ era
Packing & Delivery
Trina Projects
Delivery & Payment Terms
|
Payment Terms
|
T/T
|
EXW
|
30% in advance for deposit payment, the balance payments will be paid before shipment.
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR/C&F
|
30% in advance for deposit payment, the balance will be paid against copy of B/L
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
L/C
|
Optional for the amount of above 50,000 usd, L/C at sight is acceptable.
|
|
|
|||
|
|
West Union
|
Optional for amount of order less than 5000 usd
|
|
|
|||
|
|
Paypal
|
|
|
|
|||
|
Delivery Time
|
7~30 days after receiving the payment or the deposit payment
|
|
|
|
|||
