Quick Details
-
Marketing Type:
-
Hot Product
-
Reverse Speed(km/h):
-
23
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
bigbund
-
Weight:
-
20000 kg
-
Dimension(L*W*H):
-
8970*2625*3470mm
-
Rated Power:
-
153KW
-
Transport Weight:
-
16500KG
-
Product name:
-
GR215 Motor Grader
-
Feature:
-
Motor Grader
-
Max Paving Speed:
-
38KM/h
-
Max gradeability:
-
20%
-
Maximum Lift Above Ground:
-
450mm
-
Circle reversing rotation:
-
360°
Quick Details
-
Forward Speed(km/h):
-
38
-
Engine Brand:
-
weichai
-
Working diameter:
-
1600mm
-
Marketing Type:
-
Hot Product
-
Reverse Speed(km/h):
-
23
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
bigbund
-
Weight:
-
20000 kg
-
Dimension(L*W*H):
-
8970*2625*3470mm
-
Rated Power:
-
153KW
-
Transport Weight:
-
16500KG
-
Product name:
-
GR215 Motor Grader
-
Feature:
-
Motor Grader
-
Max Paving Speed:
-
38KM/h
-
Max gradeability:
-
20%
-
Maximum Lift Above Ground:
-
450mm
-
Circle reversing rotation:
-
360°
GR series graders are mainly used for road, airport, farmland and other large areas of ground leveling and ditching, slope scraping, bulldozing, soil loosening, snow removal and other operations . It is the necessary engineering machinery for national defense engineering, mine construction, urban and rural road construction, water conservancy construction, farmland improvement, etc.
Product advantages:
♠ New Appearance Design.
♠ Articulated frame with front wheel steering , small turning radius and flexible maneuverability.
♠ Electro-hydraulic control power shift gearbox, 6 gears forward and 3 gears backward.
♠ Internationalized hydraulic fittings, reliable operation.
♠ The action of spade is controlled by full hydraulic pressure.
♠ The rear axle is a three-stage drive axle equipped with NO-SPIN self-locking differential.
♠ The control platform and seat can be adjusted, the control handle and instrument are arranged reasonably, the use is convenient, and the driving comfort is improved.
♠ The cab is luxurious and beautiful , with wide vision and good sealing.
♠ It can be equipped with front bulldozer, back looser, front looser rake and automatic leveling device.
Rated parameters:
| Item | Parameters | Unit |
| Engine Model | 6CTA8.3-C215 | |
| Rated power/speed | 160/2200 | kW/rpm |
| Exterior dimensions of the whole machine (standard) | 8970×2625×3420 | m m |
| Weight of the whole machine (standard) | 16500 | kg |
| Speed of advance | 5,8,11,19,23,38 | km/h |
| reverse speed | 5,11,23 | km/h |
| Traction f = 0.75 | 90 | kN |
| Max Climb Capability | 20 | % |
| Maximum lifting height | 450 | mm |
| Minimum turning radius | 7.3 | m |
| Maximum shovel depth | 500 | mm |
| Maximum roll angle | 90 | ° |
| Return angle | 360 | ° |
The grader is a high-speed, high-efficiency, high-precision and multi-purpose earthwork construction machinery. It can complete the work of leveling and digging trenches, scraping slopes, bulldozing, snow removal, loosening, compacting, cloth, mixing, assisting installation and opening wasteland in large areas such as highway important content fields and farmland. It is an important equipment in national defense engineering, mine construction, road construction, water conservancy construction and farmland improvement.
