Quick Details
-
Optical Resolution:
-
640*480
-
Scan Speed:
-
fast
-
Brand Name:
-
syble
-
Place of Origin:
-
Guangdong, China
-
Image(Pixels):
-
640 pixels (H) x 480 pixels(V)
-
Scanning range:
-
0-190mm(EAN 13 13mil, PCS=90%)
-
Field of view:
-
44°(H), 34°(V)
-
Interface:
-
USB(Drive-Free), RS232, USB-COM
-
Scan Mode:
-
Continuous Scanning
-
Recognition angle range:
-
Turn angle ±360°, elevation angle ±65°, declination angle ±65°
-
Dimension:
-
80mm*68.4mm*160mm
-
Minimum recognition accuracy:
-
Code 39 4mil
-
System compatibility:
-
Linux,Android,Windows XP,7,8,10,MAC
-
Print contrast:
-
20%
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Max Paper Size:
-
A4 size
-
Optical Resolution:
-
640*480
-
Scan Speed:
-
fast
-
Brand Name:
-
syble
-
Place of Origin:
-
Guangdong, China
-
Image(Pixels):
-
640 pixels (H) x 480 pixels(V)
-
Scanning range:
-
0-190mm(EAN 13 13mil, PCS=90%)
-
Field of view:
-
44°(H), 34°(V)
-
Interface:
-
USB(Drive-Free), RS232, USB-COM
-
Scan Mode:
-
Continuous Scanning
-
Recognition angle range:
-
Turn angle ±360°, elevation angle ±65°, declination angle ±65°
-
Dimension:
-
80mm*68.4mm*160mm
-
Minimum recognition accuracy:
-
Code 39 4mil
-
System compatibility:
-
Linux,Android,Windows XP,7,8,10,MAC
-
Print contrast:
-
20%
Specification
|
Performance Parameters |
|
|
Image(Pixels) |
640 pixels (H) x 480 pixels(V) |
|
Supported Symbologies |
1D:EAN-8,EAN-13,EAN-13 2 add-on,EAN-13 5 add-on,ISSN,ISBN,UPC-A,UPC-E,Code11,Code 32,Code 39,Code 93,Code 128,Codabar,Industrial 2 of 5,Interleaved 2 of 5,Matrix 2 of 5,ISBT-128,GS1-128,GS1 DataBar(RSS14),GS1 DataBar Limited,GS1 DataBar Expanded. 2D:PDF417,MicroPDF417,QR-code,MicroQR, Data Matrix,QR,Aztec. |
|
Scan Range |
5mil(Code39) 1cm~15cm; UPC-13mil 1cm~33cm; 20mil(code39) 1cm~40cm; 20mil(QR Code) 1cm~28cm |
|
System compatibility |
Linux,Android,Windows XP,7,8,10,MAC |
|
Minimum recognition accuracy |
Code 39 4mil |
|
Barcode Type |
1d or 2d barcodes for Paper or Film;1d and 2d for screen ,like Phone tablets |
|
Field of view |
44°(H), 34°(V) |
|
Scan Mode |
Continuous Scanning |
|
Support Keyboard |
Support Multi-Language |
|
Barcode output editing |
Support for adding suffixes |
|
Print contrast |
20% |
|
Recognition angle range |
Turn angle ±360°, elevation angle ±65°, declination angle ±65° |
|
Mutual Move |
Led: Red and blue bi-color indicator: red light reading code, blue light power indicator. Beeper: Startup prompts, reading tips. Keys (touch keys): Key Switch and 2d barcodes. |
|
Interfaces |
USB(Drive - Free),RS232, USB-COM |
|
Physical Parameters |
|
|
Dimensions |
80mm*68.4mm*160mm
|
|
Weight |
150g |
|
Material |
ABS+PC |
|
Cable Length |
200CM(±3CM) |
|
Environmental Parameters |
|
|
Operating Temperature |
-20℃~55℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Relative Humidity |
5%~95% RH(non-condensing/non-freezing) |
|
Shock Resistance: |
Withstands three times1 . 5 meters drops to concrete |
|
Waterproof and Dustproof |
IP54 standard |
|
Ambient Ligh |
0-70000LUX |
Application Area
