Quick Details
-
Brand Name:
-
H
-
Use:
-
Campus network,Data center core/aggregation node
-
Product name:
-
Core/Convergence switch
-
Switch Capacity:
-
352 Gbit/s
-
Forwarding Performance:
-
5760/38400 Mpps
-
Slots:
-
2 SRU slots & 2 LPU slots & 1 Fan Slots
-
Warranty:
-
1 Year / 12 Months
-
Dimensions ((H x W x D):
-
219.5mm*442mm*504.5mm
-
Weight (empty/fully loaded):
-
22 kg/38 kg
-
Function:
-
QoS,VXLAN,ARP,VLAN,M-LAG
-
Certificate:
-
CCC
-
Maximum power supply:
-
800 W
Quick Details
-
Type:
-
Enterprise Switch
-
Model Number:
-
S8700-4
-
Place of Origin:
-
Beijing, China
-
Brand Name:
-
H
-
Use:
-
Campus network,Data center core/aggregation node
-
Product name:
-
Core/Convergence switch
-
Switch Capacity:
-
352 Gbit/s
-
Forwarding Performance:
-
5760/38400 Mpps
-
Slots:
-
2 SRU slots & 2 LPU slots & 1 Fan Slots
-
Warranty:
-
1 Year / 12 Months
-
Dimensions ((H x W x D):
-
219.5mm*442mm*504.5mm
-
Weight (empty/fully loaded):
-
22 kg/38 kg
-
Function:
-
QoS,VXLAN,ARP,VLAN,M-LAG
-
Certificate:
-
CCC
-
Maximum power supply:
-
800 W
Product Description
China wholesale price S8700-4 network switch poe 10 port S8700 Series network switches S8700-4
|
S8700-4
|
|
⚫ Two SRUs work in active/standby mode for 1:1 hot standby. By default, the SRU with a smaller slot ID is the active SRU, and the SRU with a larger slot ID is the standby SRU.
The SRU can provide service ports ⚫ 2 slots for SRU (Switch Routing Unit), 2 slots for LPU (Line Processing Unit) ⚫ Port density per chassis: 144 x FE, 144 x GE, 64 x 10 GE ⚫ Switching capacity: 352 Gbit/s |
|
Item
|
CloudEngine S8700-4
|
CloudEngine S8700-6
|
CloudEngine S8700-10
|
||
|
Dimensions without
packaging (H x W x D) [mm(in.)] |
219.5mm*442mm*504.5mm (8.64 in. x 17.40 in. x 19.86 in.)
|
352.8mm*442mm*515.5mm (13.89 in. x 17.40 in. x 20.30 in.)
|
575mm*442 mm*515.5mm (22.64 in. x 17.40 in. x 20.30 in.)
|
||
|
Chassis height [U]
|
5 U
|
8 U
|
13 U
|
||
|
Weight without packaging (base configuration)[kg(lb)]
|
22kg (48.50lb)
|
27.04 kg (59.62 lb)
|
39.84 kg (87.85 lb)
|
||
|
Weight without packaging (full configuration) [kg(lb)]
|
38kg (83.78)
|
64.24 kg (141.65 lb)
|
97.35 kg (214.66 lb)
|
||
|
Switching capacity
|
352Gbps
|
2.4Tbps
|
3.2Tbps
|
||
|
Main Control Board Slots
|
2
|
2
|
2
|
||
|
Service Card Slots
|
2
|
4
|
8
|
||
|
Fan Slots
|
1
|
2
|
2
|
||
|
System Power Supplies
|
6
|
6
|
6
|
||
|
Redundant MPUs
|
The control unit and switching unit work in hot standby (1:1) mode.
|
The control unit and switching unit work in hot standby (1:1) mode.
|
The control unit and switching unit work in hot standby (1:1) mode.
|
||
|
Redundant power supply
|
⚫ Dual-power input: The N+0 and N+1 modes are supported. The N+1 mode is recommended.
⚫ Single-power input: The N+0, N+1, and N+N modes are supported. The N+1 mode is recommended. |
⚫ Dual-power input: The
N+0 and N+1 modes are supported. The N+1 mode is recommended. ⚫ Single-power input: The N+0, N+1, and N+N modes are supported. The N+1 mode is recommended. |
⚫ Dual-power input: The N+0
and N+1 modes are supported. The N+1 mode is recommended. ⚫ Single-power input: The N+0, N+1, and N+N modes are supported. The N+1 mode is recommended. |
||
|
Redundant fans
|
The fan module can tolerate the failure of a single fan. When a single fan in the fan module is faulty, the system can work properly for a short period of time. However, you are advised to replace the faulty fan module immediately.
|
Fan modules work in hot standby mode. The system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately.
|
Fan modules work in hot
standby mode. The system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. |
||
|
Rated input voltage [V]
|
⚫ DC input: –48 V DC/–60 V DC/48 V DC
⚫ AC input: 110 V AC/220 V AC, 50/60 Hz ⚫ High-voltage DC input: 240 V DC |
⚫ DC input: –48 V DC/–60
V DC/48 V DC ⚫ AC input: 110 V AC/220 V AC, 50/60 Hz ⚫ High-voltage DC input: 240 V DC |
⚫ DC input: –48 V DC/–60 V
DC/48 V DC ⚫ AC input: 110 V AC/220 V AC, 50/60 Hz ⚫ High-voltage DC input: 240 V DC |
||
|
Input voltage range [V]
|
⚫ DC input: -38.4 V DC to - 72 V DC
⚫ AC input: 90–290 V AC; 45–65 Hz ⚫ High-voltage DC input: 190 V DC to 290 V DC |
⚫ DC input: -38.4 V DC to -
72 V DC ⚫ AC input: 90–290 V AC; 45–65 Hz ⚫ High-voltage DC input: 190 V DC to 290 V DC |
⚫ DC input: -38.4 V DC to -
72 V DC ⚫ AC input: 90–290 V AC; 45–65 Hz ⚫ High-voltage DC input: 190 V DC to 290 V DC |
||
|
Maximum power
consumption [W] |
638 W (full configuration, without PoE)
|
1560 W (full configuration, without PoE)
|
2914 W (full configuration, without PoE)
|
||
|
Maximum power output
capability (including the system power output and PoE power output) [W] |
⚫ Configured with six 1000 W AC power modules: 6000 W
⚫ Configured with six 600 W DC power modules: 3600W ⚫ Configured with six 1000 W DC power modules: 1000 W
⚫ Intermixing of N 1000 W power modules and M 600 W DC power modules: (N+M) x 600 W
|
⚫ Configured with six 2500 W/3000 W AC&240 V DC power modules: 15000 W (220 V AC input or 240 V DC input; the output power of a single power module is 2500 W)
⚫ Configured with six 2200 W DC power modules: 13200 W ⚫ Intermixing of N 2500 W/3000 W AC&240 V DC power modules and M 2200 W DC power modules: (N+M) x 2200 W
NOTE
In V600R021C10 and later versions, the 3000 W output capability of the AC power module (2500 W/3000 W AC&240 V DC power module) can be enabled using a command.
|
⚫ Configured with six 2500 W/3000 W AC&240 V DC power modules: 15000 W (220 V AC input or 240 V DC input; the output power of a single power module is 2500 W)
⚫ Configured with six 2200 W DC power modules: 13200 W ⚫ Intermixing of N 2500 W/3000 W AC&240 V DC power modules and M 2200 W DC power modules: (N+M) x 2200 W
NOTE
In V600R021C10 and later versions, the 3000 W output
capability of the AC power module (2500 W/3000 W AC&240 V DC power module) can be enabled using a command. |
||
|
Long-term operating
temperature [°C(°F)] |
-5°C to 45°C (23°F to 113°F) at an altitude of -60 m to 1800 m (-197 ft. to 5906 ft.)
|
-5°C to 45°C (23°F to 113°F) at an altitude of -60 m to 1800 m (-197 ft. to 5906 ft.)
|
-5°C to 45°C (23°F to 113°F) at an altitude of -60 m to 1800 m (-197 ft. to 5906 ft.)
|
||
|
Short-term operating
temperature [°C(°F)] |
55°C (131°F) at an altitude of -60 m to 1800 m (-197 ft. to 5906 ft.)
NOTE 1.Under the short-term operating temperature, the system supports only optical modules with less than or equal to 10 km transmission distances. |
55°C (131°F) at an altitude of -60 m to 1800 m (-197 ft. to 5906 ft.)
NOTE 1.When the PAC3KS54-DF (2500 W/3000 W AC&240 V DC power module) is used, the device can work at 55°C (131°F) for a short period only when the system works in the N+1 power supply mode (the output power of a single power module is less than 2100 W). 2.Under the short-term operating temperature, the system supports only optical modules with less than or equal to 10 km transmission distances. |
55°C (131°F) at an altitude of -
60 m to 1800 m (-197 ft. to 5906 ft.) NOTE 1.When the PAC3KS54-DF (2500 W/3000 W AC&240 V DC power module) is used, the device can work at 55°C (131°F) for a short period only when the system works in the N+1 power supply mode (the output power of a single power module is less than 2100 W). 2.Under the short-term operating temperature, the system supports only optical modules with less than or equal to 10 km transmission distances. |
||
|
Relative humidity
|
5% to 95% (non-condensing)
|
|
|
||
|
Heat dissipation mode
|
Air intake from the front and exhaust from the rear; Air extraction and heat dissipation, intelligent speed adjustment
|
|
|
||
Product Paramenters
|
Category
|
Service Features
|
|
User management
|
Unified user management
|
|
|
PPPoE, 802.1X, MAC, authentication
|
|
|
Traffic- and duration-based accounting
|
|
|
User authorization based on user groups, domains, and time ranges
|
|
|
HTTP/HTTPS Access
|
|
MAC address
|
Maximum number of MAC entries:384K(MAX)
|
|
|
Automatic MAC address learning and aging
|
|
|
Static, dynamic, and blackhole MAC address entries
|
|
|
Source MAC address filtering
|
|
|
MAC address learning limiting based on ports and VLANs
|
|
VLAN
|
4K VLANs
|
|
|
Access mode, Trunk mode and Hybrid mode
|
|
|
Default VLAN
|
|
|
VLAN stacking
|
|
|
QinQ and enhanced selective QinQ
|
|
|
Dynamic VLAN assignment based on MAC addresses
|
|
ARP
|
ARP Snooping
|
|
IP routing
|
IPv4 dynamic routing protocols such as RIP, OSPF, IS-IS, and BGP
|
|
|
IPv6 dynamic routing protocols such as RIPng, OSPFv3, ISISv6, and BGP4+
|
|
Segment Routing
|
SRv6 BE (L3 EVPN)
|
|
|
BGP EVPN
|
|
|
SRv6 configuration through NETCONF
|
|
Multicast
|
IGMPv1/v2/v3 and IGMP v1/v2/v3 Snooping
|
|
|
PIM-DM, PIM-SM, and PIM-SSM
|
|
|
Fast-leave mechanism
|
|
|
Multicast traffic control
|
|
|
Multicast querier
|
|
|
Multicast protocol packet suppression
|
|
VXLAN
|
Centralized gateway
|
|
|
Distributed gateway
|
|
|
BGP-EVPN
|
|
|
Configures VXLANs through NETCONF
|
|
QoS
|
Traffic classification based on Layer 2 headers, Layer 3 protocols, Layer 4 protocols, and 802.1p priority
|
|
|
Actions such as ACL, Committed Access Rate (CAR), re-marking, and scheduling
|
|
|
Queuing algorithms, such as PQ, DRR and PQ+DRR
|
|
|
Congestion avoidance mechanisms such as WRED and tail drop
|
|
|
Traffic shaping
|
|
|
Network Slicing
|
|
Native-IP IFIT
|
Marks the real service packets to obtain real-time count of dropped packets and packet loss ratio
|
|
|
The statistical period can be modified
|
|
|
Two-way frame delay measurement
|
|
Ring network
protection |
STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s).
|
|
|
BPDU protection, root protection, and loop protection
|
|
|
G.8032 Ethernet Ring Protection Switching (ERPS)
|
|
Reliability
|
M-LAG
|
|
|
CSS
|
|
|
Link Aggregation Control Protocol (LACP) and E-
Trunk |
|
|
Virtual Router Redundancy Protocol (VRRP) and Bidirectional Forwarding Detection (BFD) for VRRP
|
|
|
BFD for BGP/IS-IS/OSPF/static routes
|
|
|
Eth-OAM 802.1ag
|
|
|
Smart Link
|
|
System
Management |
Terminal access services such as console port login, Telnet, and SSH
|
|
|
Network management protocols, such as SNMPv1/v2/v3
|
|
|
File uploading and downloading through FTP,TFTP and SFTP
|
|
|
BootROM upgrade and remote in-service upgrade
|
|
|
Hot patches
|
|
|
User operation logs
|
|
|
Open Programmability System (OPS)
|
|
|
Streaming Telemetry
|
|
|
Port Mirroring
|
|
Security and
management |
MACsec
|
|
|
NAC
|
|
|
RADIUS and HWTACACS authentication for login users
|
|
|
Command line authority control based on user levels, preventing unauthorized users from using command configurations
|
|
|
Defense against DoS attacks, Transmission Control Protocol (TCP) SYN Flood attacks, User Datagram Protocol (UDP) Flood attacks, broadcast storms, and heavy traffic attacks
|
|
|
IPv6 RA Guard
|
|
|
CPU hardware queues to implement hierarchical scheduling and protection for protocol packets on the control plane
|
|
|
Remote Network Monitoring (RMON)
|
|
|
Secure boot (need to use MPU that supports secure boot)
|
