Quick Details
-
CPU:
-
J1900/I3/i5/i7/rk3288/rk3399
-
Application:
-
Indoor/outdoor
-
Size:
-
23/27/32 inch
-
Touch points:
-
10 Points
-
Response time:
-
5ms
-
Brightness:
-
250-1000cd/m2
-
Touch type:
-
G+G capacitive
-
Warranty:
-
1 Year
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Crtly
-
Operating System:
-
Win xp/7/8/10 Android
-
CPU:
-
J1900/I3/i5/i7/rk3288/rk3399
-
Application:
-
Indoor/outdoor
-
Size:
-
23/27/32 inch
-
Touch points:
-
10 Points
-
Response time:
-
5ms
-
Brightness:
-
250-1000cd/m2
-
Touch type:
-
G+G capacitive
-
Warranty:
-
1 Year
Product Description
Specification
|
1. Main Body
|
|
|
|
|||
|
Model
|
CRT-203
|
CRT-202
|
CRT-201
|
|||
|
Screen size
|
23 Inch
|
27 Inch
|
32 Inch
|
|||
|
Display scale
|
16:9
|
16:9
|
16:9
|
|||
|
Resolution
|
1920*1080
|
1920*1080
|
1920*1080
|
|||
|
Brightness
|
250 cd/m2
|
300 cd/m2
|
350 cd/m2
|
|||
|
Contrast ratio
|
1000:1
|
3000:1
|
1000:1
|
|||
|
Response time
|
5ms
|
5ms
|
5ms
|
|||
|
Touch Model
|
Capacitive 10 points
|
Capacitive 10 points
|
Capacitive 10 points
|
|||
|
Built-in Speaker
|
2
|
2
|
2
|
|||
|
Outer Frame color
|
Black/White
|
Black/White
|
Black/White
|
|||
|
Power
|
Type: external power adapter
|
Type: external power adapter
|
Type: external power adapter
|
|||
|
|
Input voltage: 100-240 V AC, 50-60 Hz
|
Input voltage: 100-240 V AC, 50-60 Hz
|
Input voltage: 100-240 V AC, 50-60 Hz
|
|||
|
Temper glass
|
Yes
|
Yes
|
Yes
|
|||
|
Dimension
|
555mm(L)*355mm(W)*1425mm(H)
|
606mm(L)*380mm(W)*1640mm(H)
|
606mm(L)*367mm(W)*1729mm(H)
|
|||
|
Display size
|
509.1mm*286.4mm
|
597.6*336.1mm
|
765mm*459mm
|
|||
|
Working environment
|
Operating temperature. -10～50°C ；Storage temperature -20～60°C
|
Operating temperature. -10～50°C ；Storage temperature -20～60°C
|
Operating temperature. -10～50°C ；Storage temperature -20～60°C
|
|||
|
|
Working humidity 10%～90% ；Storage humidity 10%～90%
|
Working humidity 10%～90% ；Storage humidity 10%～90%
|
Working humidity 10%～90% ；Storage humidity 10%～90%
|
|||
|
Wireless scanner
|
YES
|
YES
|
YES
|
|||
|
2. Touch screen and PC
|
|
|
|
|||
|
Model
|
Capacitive touch LED
|
Capacitive touch LED
|
Capacitive touch LED
|
|||
|
Touch Object
|
Finger, Pen,any conductive object
|
Finger, Pen,any conductive object
|
Finger, Pen,any conductive object
|
|||
|
Touch accuracy
|
≥2
|
≥2
|
≥2
|
|||
|
Light transmit ratio
|
85%
|
85%
|
85%
|
|||
|
Glass Hardness
|
7
|
7
|
7
|
|||
|
Response time
|
≤5 ms
|
≤5 ms
|
≤5 ms
|
|||
|
Output resolution
|
4096*4096(touch screen)
|
4096*4096(touch screen)
|
4096*4096(touch screen)
|
|||
|
LED Backlight Life(Min)
|
30,000 hours
|
30,000 hours
|
30,000 hours
|
|||
|
Interface
|
USB*4,RS232*2,RJ45*1
|
USB*4,RS232*2,RJ45*1
|
USB*4,RS232*2,RJ45*1
|
|||
|
Protection level
|
IP56
|
IP56
|
IP56
|
|||
|
CPU
|
X86 Corei3-i7/RockChip RK3288
|
X86 Corei3-i7/RockChip RK3288
|
X86Corei3-i7/RockChip RK3288
|
|||
|
Frequency（H/V）
|
30～80KHz / 60～75Hz
|
30～80KHz / 60～75Hz
|
30～80KHz / 60～75Hz
|
|||
|
RAM
|
2G/4G/8G
|
2G/4G/8G
|
2G/4G/8G
|
|||
|
SSD
|
128GB SSD
|
128GB SSD
|
128GB SSD
|
|||
|
WIFI
|
yes
|
yes
|
yes
|
|||
|
3. Card reader（LS682X）
|
|
|
|
|||
|
Communication Interface
|
USB-HD; USB-CDC; UART; RS232; RS485
|
USB-HD; USB-CDC; UART; RS232; RS485
|
USB-HD; USB-CDC; UART; RS232; RS485
|
|||
|
Protocol type
|
13.56MHz(A): ISO14443A ; 13.56MHz(A)+125KHz: ISO14443A+ISO18000-2
|
13.56MHz(A): ISO14443A ; 13.56MHz(A)+125KHz: ISO14443A+ISO18000-2
|
13.56MHz(A): ISO14443A ; 13.56MHz(A)+125KHz: ISO14443A+ISO18000-2
|
|||
|
Identifiable card type
|
ISO14443A protocol card: S50、S70、FM1208、UltraLight、MifareProX、DESFire;
|
ISO14443A protocol card: S50、S70、FM1208、UltraLight、MifareProX、DESFire;
|
ISO14443A protocol card: S50、S70、FM1208、UltraLight、MifareProX、DESFire;
|
|||
|
|
ISO1800-2 Protocol card: TK4100、EM4100、EM4205、EM4305
|
ISO1800-2 Protocol card: TK4100、EM4100、EM4205、EM4305
|
ISO1800-2 Protocol card: TK4100、EM4100、EM4205、EM4305
|
|||
|
Dimensions (mm)
|
105 mm (L) x 70 mm (W) x 12 mm (H)
|
105 mm (L) x 70 mm (W) x 12 mm (H)
|
105 mm (L) x 70 mm (W) x 12 mm (H)
|
|||
|
Read and write distance
|
5-100mm
|
5-100mm
|
5-100mm
|
|||
|
Working frequency
|
Mixing: 13.56MHz+125KHz;
|
Mixing: 13.56MHz+125KHz;
|
Mixing: 13.56MHz+125KHz;
|
|||
|
4. Connection & Ports
|
|
|
|
|||
|
Protocol
|
USB CCID
|
USB CCID
|
USB CCID
|
|||
|
Power Source((External)
|
From USB port
|
From USB port
|
From USB port
|
|||
|
Speed
|
USB Full Speed (12 Mbps)
|
USB Full Speed (12 Mbps)
|
USB Full Speed (12 Mbps)
|
|||
|
Cable Length
|
1.8m, Fixed
|
1.8m, Fixed
|
1.8m, Fixed
|
|||
|
RS232 PORT/COM (Built in)
|
2 unit
|
2 unit
|
2 unit
|
|||
|
USB port(Built in)
|
4 unit
|
4 unit
|
4 unit
|
|||
|
VGA port(Built in)
|
1 unit
|
1 unit
|
1 unit
|
|||
|
ETH port/RJ45(External)
|
1 unit
|
1 unit
|
1 unit
|
|||
|
Audio outport
|
1 unit
|
1 unit
|
1 unit
|
|||
|
5. Built-in Peripherals
|
|
|
|
|||
|
LED(( Optional), The default is no
|
Colorful(Optional)
|
Colorful(Optional)
|
Colorful(Optional)
|
|||
|
6. Certifications
|
|
|
|
|||
|
Certifications/Compliance
|
CE, FCC, RoHS, REACH,3C
|
CE, FCC, RoHS, REACH,3C
|
CE, FCC, RoHS, REACH,3C
|
|||
|
7. Device Driver Operating System Support
|
|
|
|
|||
|
Operating System Support
|
Win7/8/10 Android (Optional)
|
Win7/8/10 Android (Optional)
|
Win7/8/10 Android (Optional)
|
|||
