Quick Details
-
Model Number:
-
SPV320M
-
Place of Origin:
-
Ho Chi Minh City, Vietnam
-
Number of Cells:
-
72pcs
-
Panel Dimensions:
-
1971 x 994 x 50
-
Max. Power::
-
320 W
-
Frame::
-
Aluminium
-
Junction Box::
-
IP65
Quick Details
-
Max. Power:
-
320W
-
Material:
-
Monocrystalline Silicon
-
Brand Name:
-
SPV
-
Model Number:
-
SPV320M
-
Place of Origin:
-
Ho Chi Minh City, Vietnam
-
Number of Cells:
-
72pcs
-
Panel Dimensions:
-
1971 x 994 x 50
-
Max. Power::
-
320 W
-
Frame::
-
Aluminium
-
Junction Box::
-
IP65
Product Description
| ELECTRICAL SPECIFICATIONS | 320 |
| Maximum Power Pmax | 320 W (±3%) |
| Voltage at Maximum Power Point Vmp (V) | 37.6 |
| Current at Maximum Power Point Imp (A) | 8.52 |
| Open Circuit Voltage Voc (V) | 41.5 |
| Short Circuit Current Isc (A) | 8.63 |
| Dimession (mm) | 1971 x 994 x 50 |
| J-Box | IP65 |
| Temperature Coefficient of Voc | -0.084 V/ºC (-0.38% /ºC) |
| Temperature Coefficient of Isc | 4.4x10-3 A/ºC (0.05% /ºC) |
| Temperature Coefficient of Pmax | -0.75 W/ºC (-0.50% /ºC) |
| Warranty | 5 years |
| Weight (Kg) | 18.6 kg |
| Material | Solar World Mono Cell (German) |
