Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Modo
-
Model Number:
-
MS
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
As customer request
-
Cable Length:
-
/
-
Outlet Size:
-
As customer request
-
Power:
-
As customer request
-
Theory:
-
Centrifugal Pump
-
Standard or Nonstandard:
-
Standard
-
Product name:
-
high volume low pressure electric water pumps
-
Material:
-
Cast Iron/Cast steel/Stainless Steel
-
Lubrication:
-
Grease and Oil
-
Color:
-
Customer specifications upon request
Quick Details
-
Application:
-
Drinking water treatment, HVAC OEM, Industrial Utilities, Irrigation and Agriculture, Mining industry, Raw Water Intake, Water Distribution, Flood drainage
-
Pressure:
-
As customer request, High Pressure
-
Voltage:
-
220V/380V/400V/420V, 50Hz/60Hz
-
Warranty:
-
1 year
-
Brand Name:
-
Modo
-
Model Number:
-
MS
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
As customer request
-
Cable Length:
-
/
-
Outlet Size:
-
As customer request
-
Power:
-
As customer request
-
Theory:
-
Centrifugal Pump
-
Standard or Nonstandard:
-
Standard
-
Product name:
-
high volume low pressure electric water pumps
-
Material:
-
Cast Iron/Cast steel/Stainless Steel
-
Lubrication:
-
Grease and Oil
-
Color:
-
Customer specifications upon request
-- Products Description --
MS
Split case pump
MS type Split casing water pump
1000 cubic meter per hour is a Split casing water pump. It is used totransport pure water and the liquid which physical and chemical nature is similar with water the
maximum temperature isn't more than 80 ℃.
This series of pump
is suitable for water supply and drainage in factories, mines and cities, power station, drainage and irrigation of farming, and
kinds of hydraulic projects.
-- Details Images --
-- Product Parameters --
|
Model
|
Inlet/Outlet
(mm)
|
Capacity
m³/h
|
Head
m
|
Speed
(rpm)
|
Shaft power(kw)
|
|
200S-95
|
200/200
|
280
|
95
|
2900
|
94
|
|
200S-63
|
200/200
|
280
|
63
|
2900
|
59.3
|
|
200S-42
|
200/200
|
280
|
42
|
2900
|
37.7
|
|
250S-65
|
250/250
|
485
|
65
|
1450
|
108.7
|
|
250S-39
|
250/250
|
485
|
39
|
1450
|
62.1
|
|
250S-24
|
250/250
|
485
|
24
|
1450
|
36.9
|
|
250S-14
|
250/250
|
485
|
14
|
1450
|
21.7
|
|
300S-90
|
300/300
|
790
|
90
|
1450
|
249.8
|
|
300S-58
|
300/300
|
790
|
58
|
1450
|
148.5
|
|
300S-32
|
300/300
|
790
|
32
|
1450
|
79
|
|
300S-19
|
300/300
|
790
|
19
|
1450
|
46.9
|
|
300S-12
|
300/300
|
790
|
12
|
1450
|
31.1
|
|
350S-125
|
350/350
|
1260
|
125
|
1450
|
531
|
|
350S-75
|
350/350
|
1260
|
75
|
1450
|
304
|
|
350S-44
|
350/350
|
1260
|
44
|
1450
|
177.6
|
|
350S-26
|
350/350
|
1260
|
26
|
1450
|
101.5
|
|
350S-16
|
350/350
|
1260
|
16
|
1450
|
63.8
|
|
500S-13
|
500/500
|
2020
|
13
|
980
|
86.2
|
|
500S-35
|
500/500
|
2020
|
35
|
980
|
219
|
|
500S-98
|
500/500
|
2020
|
98
|
980
|
678
|
|
600S22
|
600/600
|
3241
|
22
|
980
|
231.8
|
|
600S75
|
600/600
|
3060
|
75
|
980
|
694.4
|
|
800S32
|
800/800
|
5500
|
32
|
730
|
538.5
|
|
800S47
|
800/800
|
5500
|
47
|
730
|
782.2
|
