Quick Details
-
Brand Name:
-
JARCH
-
Model Number:
-
Motor cable reel 001
-
Shaft Material:
-
Steel,Can be customized stainless steel
-
Cord Length:
-
100 ft.
-
Cord Included:
-
No
-
Hose I.D.:
-
1/2"
-
Reel Grade:
-
Heavy Duty
-
Drive Type:
-
115 V AC Motor
-
Max Pressure:
-
5000
-
Warehouse:
-
China
-
Max Temperature (°F):
-
212
-
Product name:
-
Retractable Heavy Duty Motor Driven Cable Reel
Quick Details
-
Male End Type:
-
DC Plug
-
Female End Type:
-
Stripped
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JARCH
-
Model Number:
-
Motor cable reel 001
-
Shaft Material:
-
Steel,Can be customized stainless steel
-
Cord Length:
-
100 ft.
-
Cord Included:
-
No
-
Hose I.D.:
-
1/2"
-
Reel Grade:
-
Heavy Duty
-
Drive Type:
-
115 V AC Motor
-
Max Pressure:
-
5000
-
Warehouse:
-
China
-
Max Temperature (°F):
-
212
-
Product name:
-
Retractable Heavy Duty Motor Driven Cable Reel
Retractable Heavy Duty Electric Motor Driven Cable Reel
Retractable Heavy Duty Electric Motor Driven Cable Reel
| JARCH' s Series 30000 hose reels are designed for rugged, heavy duty applications requiring long lengths of hose and large storage capacity. All-bolted unitized construction with no welds to fatigue, full flow swivel and heavy gauge steel frame, spool. |
Reel Specifications and Dimensions
Benefits
***High pressure water swivel - Designed to handle a broad range of pressures, temperatures, and chemicals; perfect for agriculture / marine, equipment cleaning and pressure washing applications.
***Full flow, stress-free swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life.
***Quality finish and corrosion resistant - Individually powder coated components offer the maximum protection from premature corrosion.
***Easy to add tension - The T-handle tensioning device allows proper tension to be applied to the spool to eliminate the free spooling of the reel.
Retractable Heavy Duty Electric Motor Driven Cable Reel
Technicals Bulletins
Hand crank to 24V electric motor conversion requirements
Kit #S600771 CA33112 L to EA33112 L24D
| Qty. | Part # | Description |
| 1 | 260450 | Drive Motor |
|
1 |
260405 | Motor Bracket |
| 1 | 260406 | Drive Chain |
| 1 | 260407 | Spool Gear |
| 1 | 260408 | Motor Gear |
| 8 | 300039 | Washer |
| 8 | S2-52 | Hex Cap Screw |
| 4 | 300107 | Lock Nut |
| 6 | S27-112 | Flat Cap Socket Screw |
| 6 | S79-3 | Flange Nut |
| 6 | 260410 | Gear Spacer |
Structure
Series 30000 Electric Motor Driven Reels
Jarch main products:
1. Fiber optic rotary joint series
2. Through bore slip ring series
3. Electro optical slip ring series
5. Pneumatic rotary joint series
6. Hydraulic rotary union series
9. High current slip ring seriels
10. High speed slip ring series
11. Thermocouple slip ring series
12. Miniature slip ring series
13. Wind turbine slip ring series
15. Explosion proof slip ring series
17.Waterproof slip ring series
| Packaging Details: | Standard Export carton Package |
| Delivery Details: |
Delivery time for Sample: 3 days / Delivery time for Order depends on quantity
Shipping:BY DHL, FedEx, UPS or TNT...... |
