Quick Details
-
IN/OUT:
-
signal input/output
-
DC/5V:
-
USB type-C power input
-
RF power:
-
21dbm
-
Power supply:
-
The power adapter: DC 5V/1A
-
Power dissipation:
-
MAX 3W
-
Dimension:
-
116*68*20mm
-
Modulation mode:
-
OFDM
-
Bandwidth:
-
20MHz
-
Frequency:
-
5150~5250MHz,5475~5850MHz
-
Temperature:
-
Operating: -5℃ ~ +70℃
Quick Details
-
Brand Name:
-
OEM ODM
-
Model Number:
-
M-HW200PRO UK
-
Place of Origin:
-
GUA
-
IN/OUT:
-
signal input/output
-
DC/5V:
-
USB type-C power input
-
RF power:
-
21dbm
-
Power supply:
-
The power adapter: DC 5V/1A
-
Power dissipation:
-
MAX 3W
-
Dimension:
-
116*68*20mm
-
Modulation mode:
-
OFDM
-
Bandwidth:
-
20MHz
-
Frequency:
-
5150~5250MHz,5475~5850MHz
-
Temperature:
-
Operating: -5℃ ~ +70℃
Our Service:
1.We can provide OEM service.
2.Your inquiry and E-mail would be replied in 2hrs.
3. Fast delivery.
4. We can print customer's logo on products according to our customer's requirements.
5. We have professional team, who can help you to solve all questions about our products.
Products Description
|
Description
|
|
Parameter
|
|
|
Video
|
Standards
|
HD 1.3; HDCP 1.2
|
|
|
|
Compression format
|
H.264
|
|
|
|
Maximum pixel clock
|
165MHz
|
|
|
|
Maximum data rate
|
6.75Gbps
|
|
|
|
Resolution
|
1920X1080P@60Hz
|
|
|
|
Connector
|
HD-A
|
|
|
|
Impedance
|
100Ω
|
|
|
|
Transmission delay
|
0.08 seconds
|
|
|
|
Recommended max HD cable Input/Output distance
|
＜5m, when 1920*1080P@60Hz
|
|
|
WIFI
|
RF power
|
21dbm
|
|
|
|
Wireless standard
|
802.11a、802.11n、802.11ac
|
|
|
|
Signal direction
|
unidirectional
|
|
|
|
Frequency
|
5150~5250MHz、5475~5850MHz
|
|
|
|
Transmission distance
|
200m in open environment
|
|
|
|
Modulation mode
|
OFDM
|
|
|
|
Bandwidth
|
20MHz
|
|
|
Other
|
Power supply
|
The power adapter: DC 5V/1A
|
|
|
|
Power dissipation
|
MAX 3W
|
|
|
|
Temperature
|
Operating: -5℃ ~ +70℃
|
|
|
|
Humidity
|
Operating: 5% ~ 90%
|
|
|
|
Dimension
|
116*68*20mm
|
|
